Aston Service Dorset: Electrical

Below are a selection of the parts that we can supply, for anything you can't find though please contact us and ask:



Aston Service Dorset: Dashboard

Aston Service Dorset : Speedo Cable   20-38-121
  Speedometer Cable RHD & LHD

Aston Service Dorset : Overdrive Speedometer Cable   24-38-121   Overdrive Speedometer Cable

Aston Service Dorset : Rev Cable RHD   20-28-124   Rev Counter Cable for RHD Cars

Aston Service Dorset : Rev Cable LHD   20-38-141   Rev Counter Cable for LHD Cars

Aston Service Dorset : Petro Flex Hose   20-38-140

20-38-035
  Petro-Flex Oil Pressure Gauge Hose

Pipe Assembly Oil Pressure Gauge for RHD Cars

Aston Service Dorset : Overdrive and Ignition Switches   20-37-132

23-37-127

20-37-128
  Spare Switch

Ignition and Starter Switch

Bezel for Ignition and Starter Switch

Back to top



Aston Service Dorset: Electrical Plate AE

Aston Service Dorset : Distributor Cap   20-07-704
  Distributor Cap Assembly

Aston Service Dorset : Distributor Parts   20-07-701

20-07-703

20-07-700

20-07-702
  Rotor Arm

Condenser

Contact Breaker Set

Distributor Sealing Ring

Aston Service Dorset : Spark Plug Shroud   20-07-135   Spark Plug Shroud

Aston Service Dorset : Dynamo Pulley   20-09-112   Dynamo Pulley for Cars up to 417

Back to top



Aston Service Dorset: Electrical Plate AF

Aston Service Dorset : Front and Rear Flasher Units   20-37-115

20-37-210

20-37-119

20-37-767
  Flasher Lamp, Amber (Not USA)

Flasher Lamp, Clear (USA Only)

Stop/Tail Flasher Unit (Not USA)

Red Lens for Stop/Tail Flasher Unit (USA Only)

Aston Service Dorset : Stop Light Switch   20-37-151

20-37-120


20-37-123
  Stop Light Switch

Number Plate, Illuminating and Reverse Lamp

Interior Light

Aston Service Dorset : Master Switch   20-37-112

20-37-109

20-37-101
  Master Switch

Control Box Regulator

Horn Relay

Aston Service Dorset : Solenoid Switch   20-37-103

20-37-104

20-37-138

  Solenoid Switch

Rubber Terminal Boot

Flasher Unit

Aston Service Dorset : Le Mans Head Lamp   20-39-113   'Le Mans' Lucas Head Lamp Unit

Aston Service Dorset : Chrome Inner Headlamp Rims   90470   Inner Headlamp Rim for the DB4

Made from polished brass and then chromed
