DBSV8, AMV8, & V8 LAGONDA

DBSV8, AMV8, & V8 LAGONDA

All parts catalogues, workshop manuals and instruction books available for these cars are below:


TECHNICAL PUBLICATIONS

The following technical manuals are available for the DBS V8, AMV8 & V8 Lagonda:

80-43-105 DBSV8 Parts Catalogue

80-43-130 DBSV8 Workshop Manual

80-40-1312 Owners Handbook 2 Headlamp

80-40-1314 Owners Handbook 4 Headlamp

43-26290 AMV8 Parts Catalogue

80-43-130 AMV8 Workshop Manual V8 Fuel Injection

95-43-123 Workshop Manual V8 Carburettor

40-26322 Owners Handbook V8 580X & EFI

43-26291 V8 Lagonda Parts Catalogue

40-148633 V8 Lagonda Owner Handbook

DBSV8

Aston Martin produced the DBS V8 from April 1970 to May 1972 and the chassis numbers ran from DBSV8/10001/R to DBSV8/10405/RCA.

The DBSV8 was capable of over 150mph and had new 15" light alloy bolt-on wheels and Girling ventilated discs.

AMV8

The AMV8 was changed extensively between 1972 and 1988 but for simplicity can be grouped in four variations.

AMV8 1972-1973 (Bosch Fuel Injection)

The AMV8 (Bosch Fuel Injection) was produced from April 1972 to July 1973 with chassis numbers running from V8/10501/RCA to V8/10789/LCA.

This was the first car produced after the David Brown era and hence lost the DB status, though the first 19 cars retained the 'David Brown Aston Martin' bonnet badge.

A total of 288 cars were made all retaining the mechanical Bosch fuel injection system.

AMV8 1973-1978 (Weber Carburettors)

The AMV8 (Weber Carburettors) version was produced from August 1973 to September 1978 with chassis numbers running from V8/11002/RCA to V8/12031/RCAS.

Significantly the Bosch fuel injection was replaced by four twin-choke downdraught Weber carburettors, this required a deeper bonnet bulge.

A total of 969 cars were made despite production stopping between December 1974 and Spring 1976 whilst the company was in receivership.

AM Oscar India V8 1978-1986

The 'Oscar India' was produced from Oct 1978 to January 1986 with chassis numbers running from V8SOR 12032 to V8SOR 12499.

The bonnet scoop was replaced with a smooth hump over the Weber carburettors and an aerodynamic spoiler was built into the boot lid.

There were 291 of these cars made.

AM Oscar India EFI V8 1986-1989

The electronic fuel injection 'Oscar India' was produced from January 1986 to October 1989 with chassis numbers running from V8SCR 12500 to V8VKR 12701.

Only 59 of these cars were made; the almost flat bonnet identifies this model which was due to the new electronically controlled Weber fuel injection system.

Other Variations

During the production of the AMV8 there were a number of Vantage, Volante and USA Cosmetic Variations, including a Prince of Wales version with extra body styling and a Zagato Vantage/Volante.

These cars made up a total of 1308.

V8 LAGONDA

The V8 Lagonda was produced from August 1974 to the end of 1989; a total of 645 were built with 30% going to the Middle East and 25% each to the UK and USA.

Essentially there were four series of the V8 Lagonda which started with David Brown's four door DBSV8 variant and finished with William Towns’ rounded off series four car.

PARTS AVAILABILITY

The majority of the parts for the DBSV8, AMV8 and V8 Lagonda are sourced directly from Aston Martin Lagonda Limited and the availability is exceptionally good.

We are able to supply all parts which are available from the Aston Martin Parts Operation and most parts immediately from our own stock.

There are a number of parts that we always have in stock and a number as new, old stock. Some are listed below, please contact us for any further details.
