product
View DiagramUncategorized
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| DBA 3.0 Litre Top Gasket Set | 16 | £30.00 | - + | |||
| test 1 | 20 | £30.00 | - + | |||
| test 2 | 6 | £30.00 | - + | |||
| test 3 | 10 | £30.00 | - + | |||
| test 4 | 14 | £30.00 | - + |
Body Fittings Front
Body Fittings Near Side
Body Fittings Off Side
Body Fittings Rear
Body Panels
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 030-03-0043 | FRONT END PANEL - complete | 1 | 2 | £30.00 | - + |
| - | 055-61-0365 | Half panel - front end - RH | 1 | 5 | £30.00 | - + |
| 2 | 055-61-0366 | Half panel - front end - LH | 1 | 19 | £30.00 | - + |
| 3 | 030-03-0044 | FRONT SUB ASSEMBLY | 1 | 19 | £30.00 | - + |
| - | 055-61-0363 | Quarter panel - RH | 1 | 20 | £30.00 | - + |
| 4 | 055-61-0364 | Quarter panel - LH | 1 | 8 | £30.00 | - + |
| 5 | 055-61-0372 | Nose underpanel | 1 | 18 | £30.00 | - + |
| 6 | 030-03-0020 | Nose top panel | 1 | 11 | £30.00 | - + |
| - | 055-61-0386 | FRONT END PANEL - complete | 1) | 16 | £30.00 | - + |
| - | 055-61-0384 | Half panel - front end - LH | 1) | 1 | £30.00 | - + |
| - | 055-61-0385 | Half panel - front end - RH | 1) | 10 | £30.00 | - + |
| - | 055171-0035 | FRONT SUB-ASSEMBLY | 1) | 15 | £30.00 | - + |
| - | 055-61-0382 | Quarter panel - LH | 1) | 6 | £30.00 | - + |
| - | 055-61-0383 | Quarter panel - RH | 1) | 9 | £30.00 | - + |
| - | 055-61-0372 | Nose underpanel | 1) | 4 | £30.00 | - + |
| - | 030-03-0020 | Nose top panel | 1) | 6 | £30.00 | - + |
| - | 031-033-0058 | Oil cooler duct | 1) | 20 | £30.00 | - + |
| 7 | 030-03-0042 | REAR END PANEL - complete | 1 | 10 | £30.00 | - + |
| - | 055-61-0361 | Half panel - rear end - RH | 1 | 16 | £30.00 | - + |
| 8 | 055-61-0362 | Half panel - rear end - LH | 1 | 15 | £30.00 | - + |
| 9 | 030-03-0002 | ROOF PANEL | 1 | 17 | £30.00 | - + |
| 10 | 030-07-0031 | BOOT LID PANEL | 1 | 10 | £30.00 | - + |
| 11 | 030-03-0027 | Lower sill panel - LH | 1 | 15 | £30.00 | - + |
| - | 030-03-0028 | Lower sill panel - RH | 1 | 1 | £30.00 | - + |
| 12 | 030-03-0026 | DOOR PANEL - LH | 1 | 19 | £30.00 | - + |
| - | 030-03-0025 | DOOR PANEL - RH | 1 | 15 | £30.00 | - + |
| 13 | 030-04-0334 | BONNET PANEL | 1 | 15 | £30.00 | - + |
| 14 | 059-67-0026 | BOOT LID PANEL | 1) | 16 | £30.00 | - + |
| 15 | 055-61-0117 | REAR END PANEL - complete | 1) | 9 | £30.00 | - + |
| 16 | 059-61-0119 | Half panel - rear end - LH | 1) | 19 | £30.00 | - + |
| - | 059-61-0118 | Half panel - rear end - RH | 1) | 12 | £30.00 | - + |
Brake and Clutch Master Cylinder
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| - | 20-33-101 | Brake Master Cylinder Complete, 7/8" bore | 1 | 17 | £30.00 | - + |
| 1 | 20-33-724 | Body | 1 | 20 | £30.00 | - + |
| 2 | 20-33-741 | Cup Seal | 1 | 13 | £30.00 | - + |
| 3 | 20-33-727 | Support, Return Spring, Inner | 1 | 12 | £30.00 | - + |
| 4 | 20-33-730 | Spring, Valve | 1 | 16 | £30.00 | - + |
| 5 | 20-33-726 | Valve | 1 | 5 | £30.00 | - + |
| 6 | 20-33-731 | Seal, Piston | 1 | 7 | £30.00 | - + |
| 7 | 20-33-729 | Return Spring | 1 | 2 | £30.00 | - + |
| 8 | 20-33-728 | Support, Return Spring, Outer | 1 | 20 | £30.00 | - + |
| 9 | 20-33-725 | Piston | 1 | 17 | £30.00 | - + |
| 10 | 20-33-736 | Recuperating Seal | 1 | 12 | £30.00 | - + |
| 11 | 20-33-733 | Push Rod | 1 | 13 | £30.00 | - + |
| 12 | 20-33-737 | Locknut, 5/16" UNF | 1 | 6 | £30.00 | - + |
| 13 | 20-33-734 | Retaining Washer | 1 | 10 | £30.00 | - + |
| 14 | 20-33-735 | Circlip, Internal | 1 | 7 | £30.00 | - + |
| 15 | 20-33-732 | Dust Excluder | 1 | 11 | £30.00 | - + |
| - | 20-33-732 | Service and Modification Kit, Brake Master Cylinder | 1 | 13 | £30.00 | - + |
| - | 20-33-104 | Clutch Master Cylinder Complete, 3/4" bore | 1 | 14 | £30.00 | - + |
| - | 20-33-753 | Kit - Clutch Master Cylinder | 1 | 14 | £30.00 | - + |
| 16 | 20-33-706 | Body | 1 | 14 | £30.00 | - + |
| 17 | 20-33-714 | Seal, Valve | 1 | 1 | £30.00 | - + |
| 18 | 20-33-712 | Stem, Valve | 1 | 13 | £30.00 | - + |
| 19 | 20-33-715 | Curved Spring Washer | 1 | 15 | £30.00 | - + |
| 20 | 20-33-713 | Spacer, Valve | 1 | 4 | £30.00 | - + |
| 21 | 20-33-711 | Return Spring | 1 | 19 | £30.00 | - + |
| 22 | 20-33-710 | Retainer, Spring | 1 | 2 | £30.00 | - + |
| 23 | 20-33-709 | Taper Seal | 1 | 17 | £30.00 | - + |
| 24 | 20-33-707 | Plunger | 1 | 20 | £30.00 | - + |
| 25 | 20-33-708 | Seal, Plunger | 1 | 6 | £30.00 | - + |
| 26 | 20-33-716 | Push Rod | 1 | 12 | £30.00 | - + |
| 27 | 20-33-717 | Retaining Washer | 1 | 10 | £30.00 | - + |
| 28 | 20-33-718 | Circlip, Internal | 1 | 7 | £30.00 | - + |
| 29 | 20-33-719 | Dust Cover | 1 | 20 | £30.00 | - + |
| - | 20-33-720 | Clip | 1 | 6 | £30.00 | - + |
| - | 20-33-721 | Retaining Band | 1 | 10 | £30.00 | - + |
| 30 | 20-33-722 | Locknut, 5/16" UNF | 1 | 1 | £30.00 | - + |
| - | 20-33-105 | Clutch Slave Cylinder Complete, 7/8" bore | 1 | 19 | £30.00 | - + |
| - | 54914 | Kit - Clutch Slave Cylinder | 1 | 14 | £30.00 | - + |
| 31 | 20-33-746 | Body | 1 | 4 | £30.00 | - + |
| 32 | 20-33-751 | Spring | 1 | 1 | £30.00 | - + |
| 33 | 20-33-747 | Seal | 1 | 7 | £30.00 | - + |
| 34 | 20-33-749 | Piston | 1 | 15 | £30.00 | - + |
| 35 | 20-33-170 | Pushrod | 1 | 2 | £30.00 | - + |
| 36 | 20-33-748 | Dust Cover | 1 | 3 | £30.00 | - + |
| 37 | 110202 | Locknut, 5/16" UNF | 1 | 15 | £30.00 | - + |
| 38 | 20-33-752 | 3/16" diam. | 1 | 15 | £30.00 | - + |
| 39 | 20-33-750 | Bleed Screw | 1 | 5 | £30.00 | - + |
| 40 | 20-33-715 | Dust Cap | 1 | 13 | £30.00 | - + |
Brake System
Brakes + Pedal Gear
Brakes and Pedal Gear
Bumpers
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 72769 | BUMPE,Front | 1 | 11 | £30.00 | - + |
| 2 | 74404 | Stiffener,Front Bumper | 1 | 20 | £30.00 | - + |
| 20 | 74600 | Plate, Backing, Support Channel | 2 | 19 | £30.00 | - + |
| 19 | 73396 | Buffer, Rubber, Support Channel | 2 | 10 | £30.00 | - + |
| 18 | 112127 | Nut, Oddie Thin 2BA | 3 | 8 | £30.00 | - + |
| 6 | 121913 | Bolt, 3/8in. BSF | 2 | 4 | £30.00 | - + |
| 17 | 119496 | Washer, Plain 3/16in. | 3 | 6 | £30.00 | - + |
| 16 | 73190 | Spacer, Number Plate Carrier | 3 | 10 | £30.00 | - + |
| 15 | 110807 | Screw, Set, 2BA x 1in. Ch. Hd. | 3 | 16 | £30.00 | - + |
| 10 | 78920 | Plate, Bearing, Rubber Block | 2 | 12 | £30.00 | - + |
| 11 | 73375 | Distance Piece, Assembly | 2 | 15 | £30.00 | - + |
| 12 | 73398 | Washer, Taper | 2 | 14 | £30.00 | - + |
| 13 | 111935 | Nut, Oddie 3/8in. BSF | 2 | 1 | £30.00 | - + |
| 14 | 73189 | Box, Number Plate Carrier | 1 | 9 | £30.00 | - + |
| 32 | 72292 | Rubber Block | 2 | 16 | £30.00 | - + |
| 31 | 74403 | Packing, Overrider | 2 | 9 | £30.00 | - + |
| 30 | 72749 | OVERRIDER | 2 | 17 | £30.00 | - + |
| 40 | 119402 | Nut, Plain 5/16in. BSF | 4 | 3 | £30.00 | - + |
| 39 | 119481 | Washer, Spring 5/16in. | 4 | 8 | £30.00 | - + |
| 26 | 122022 | Bolt, Special 5/16in. BSF | 2 | 14 | £30.00 | - + |
| 21 | 73395 | Shim, Support Channel Buffer | Nom.6 | 7 | £30.00 | - + |
| 22 | 110807 | Screw, Set, 2BA x 1in. Hex. Hd. | 4 | 7 | £30.00 | - + |
| 23 | 119488 | Washer, Spring 3/16in. | 4 | 15 | £30.00 | - + |
| 24 | 72750 | BUMPER, Rear | 1 | 18 | £30.00 | - + |
| 25 | 74493 | Stiffener, Rear Bumper | 1 | 4 | £30.00 | - + |
| 29 | 122019 | Bolt, 3/8in. BSF | 2 | 5 | £30.00 | - + |
| 33 | 72293 | Bracket, Rear | 2 | 7 | £30.00 | - + |
| 76891 | Bracket, Rear | 2 | 13 | £30.00 | - + | |
| 35 | 119482 | Washer, Spring 3/8in. | 2 | 12 | £30.00 | - + |
| 36 | 119403 | Nut, Plain 3/8in. BSF | 2 | 12 | £30.00 | - + |
| 37 | 74609 | Grommet, Rear Bracket | 2 | 6 | £30.00 | - + |
| 38 | 119230 | Bolt, 5/16in. BSF x 2in. | 4 | 11 | £30.00 | - + |
Carburettors and Manifolds
Chassis Frame Assembly
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-19-000 | Chassis Frame Assembly Complete | 1 | 6 | £30.00 | - + |
| 2 | 20-19-006 | Front Cross Member Assembly | 1 | 1 | £30.00 | - + |
| 3 | 20-20-708 | Front Member Assembly, Front Portion - R.H. | 1 | 11 | £30.00 | - + |
| 4 | 20-20-709 | Front Member Assembly, Front Portion - L.H. | 1 | 4 | £30.00 | - + |
| 5 | 20-19-003 | Front Extension Side Panel Assembly - R.H. | 1 | 7 | £30.00 | - + |
| 6 | 20-19-004 | Front Extension Side Panel Assembly - L.H. | 1 | 18 | £30.00 | - + |
| 7 | 20-19-005 | Raditor Mounting Tube Assembly | 1 | 1 | £30.00 | - + |
| 8 | 20-19-140 | Strut, Radiator Mounting - R.H. | 1 | 13 | £30.00 | - + |
| 9 | 20-19-141 | Strut, Radiator Mounting - L.H. | 1 | 19 | £30.00 | - + |
| 10 | 20-19-013 | Horn Bracket Assembly | 1 | 3 | £30.00 | - + |
| 11 | 20-22-011 | Closing Channel Assembly, Boot Floor | 1 | 14 | £30.00 | - + |
| 12 | 20-22-159 | Rear Extension Member - R.H. | 1 | 6 | £30.00 | - + |
| 13 | 20-22-160 | Rear Extension Member - L.H. | 1 | 8 | £30.00 | - + |
| 14 | 20-22-161 | Closing Piece, Rear Extension - R.H. | 1 | 12 | £30.00 | - + |
| 15 | 20-22-162 | Closing Piece, Rear Extension - L.H. | 1 | 5 | £30.00 | - + |
Chassis Frame Body etc
Chassis, Frame, Body etc
Clutch
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| - | 20-11-001 | Clutch Assembly Complete | 1 | 18 | £30.00 | - + |
| - | 20-11-730 | Cover Assembly, Clutch | 1 | 10 | £30.00 | - + |
| - | 21-11-730 | Cover Assembly | 1 | 8 | £30.00 | - + |
| - | 21-11-731 | Driven Plate | 1 | 13 | £30.00 | - + |
| - | 21-11-733 | Separator | 1 | 11 | £30.00 | - + |
| - | 21-11-734 | Driven Plate | 1 | 17 | £30.00 | - + |
| - | 21-11-705 | Release Bearing | 1 | 8 | £30.00 | - + |
| - | 21-11-742 | Adjusting Screw | 3 | 20 | £30.00 | - + |
| - | 541004 | Locknut | 3 | 20 | £30.00 | - + |
| - | 21-11-741 | Spacer | 3 | 2 | £30.00 | - + |
| - | 21-11-160 | Spacer - Cut out | 3 | 12 | £30.00 | - + |
| - | 20-33-104 | Master Cylinder | 1 | 6 | £30.00 | - + |
| - | 20-33-105 | Slave Cylinder | 1 | 18 | £30.00 | - + |
| 1 | 20-41-122 | Bell Housing, Clutch | 1 | 12 | £30.00 | - + |
| 2 | 20-41-126 | Joint - for Inspection Cover | 1 | 18 | £30.00 | - + |
| 3 | 20-41-125 | Inspection Cover | 1 | 4 | £30.00 | - + |
| 4 | 20-41-222 | Plate - for Inspection Cover | 2 | 6 | £30.00 | - + |
| 5 | 690505 | Socket Capscrew, 1/4" UNC × 1/2" | 4 | 6 | £30.00 | - + |
| 6 | 125594 | Nut, Nyloc. Thin, 3/8" UNF | 1 | 6 | £30.00 | - + |
| 7 | 119472 | Plain Washer. 3/8" | 1 | 13 | £30.00 | - + |
| 8 | 690052 | Bolt, 3/8" UNF × 3 1/8" | 1 | 18 | £30.00 | - + |
| 9 | 20-11-151 | Fork, Clutch Operating | 1 | 5 | £30.00 | - + |
| 10 | 20-11-713 | Nut, Eyebolt | 3 | 6 | £30.00 | - + |
| 11 | 20-11-712 | Eyebolt | 3 | 14 | £30.00 | - + |
| 12 | 20-11-719 | Pin, Release Lever | 3 | 8 | £30.00 | - + |
| 13 | 20-11-716 | Cover, Clutch | 1 | 17 | £30.00 | - + |
| 14 | 20-11-723 | Retainer, Release Lever Plate | 3 | 4 | £30.00 | - + |
| 15 | 20-11-718 | Strut | 3 | 1 | £30.00 | - + |
| 16 | 20-11-721 | Anti-Rattle Spring | 3 | 3 | £30.00 | - + |
| 17 | 20-11-720 | Release Lever | 3 | 11 | £30.00 | - + |
| 18 | 20-11-717 | Pressure Plate | 1 | 8 | £30.00 | - + |
| 19 | 20-11-731 | Driven Plate Assembly | 1 | 13 | £30.00 | - + |
| - | 20-11-726 | Driven Plate | 1 | 7 | £30.00 | - + |
| 20 | 20-11-732 | Facing | 2 | 14 | £30.00 | - + |
| 21 | 20-11-728 | Rivet | 42 | 3 | £30.00 | - + |
| 22 | 20-11-722 | Plate, Release Layer | 1 | 1 | £30.00 | - + |
| 23 | 20-11-729 | Thrust Spring - Violet | 12 | 9 | £30.00 | - + |
| - | 20-11-702 | Release Bearing and Retainer Assembly | 1 | 5 | £30.00 | - + |
| 24 | 20-11-715 | Release Bearing and Cup Assembly | 1 | 11 | £30.00 | - + |
| 25 | 20-11-714 | Retainer | 2 | 19 | £30.00 | - + |
| 26 | 122097 | Bush, Oilite | 1 | 7 | £30.00 | - + |
| 27 | 20-11-152 | Distance Piece | 1 | 3 | £30.00 | - + |
| 28 | 20-41-128 | Bracket, Clutch Fork Lever | 1 | 6 | £30.00 | - + |
| - | 20-41-104 | Packing Piece - Bracket | 1 | 11 | £30.00 | - + |
| 29 | 125594 | Nut, Nyloc. Thi, 3/8" UNF | 2 | 4 | £30.00 | - + |
| 30 | 690620 | Bolt, 5/16: UNF × 1 1/4" | 2 | 4 | £30.00 | - + |
| 31 | 119471 | Plain Washer, 5/16" | 2 | 9 | £30.00 | - + |
| 32 | 123115 | Nut. Nyloc, 5/16" UNF | 2 | 20 | £30.00 | - + |
| 33 | 20-33-105 | Slave Cylinder, Clutch | 1 | 1 | £30.00 | - + |
| 34 | 20-11-155 | Retaining Plate, Slave Cylinder | 1 | 8 | £30.00 | - + |
| 35 | 123131 | Bolt, 5/16" UNF × 1" | 4 | 3 | £30.00 | - + |
| 36 | 119481 | Spring Washer, 5/16" | 4 | 7 | £30.00 | - + |
| 37 | 20-11-154 | Mounting Bracket - Slave Cylinder | 1 | 19 | £30.00 | - + |
| 38 | 110202 | Locknut, 5/16" UNF | 1 | 15 | £30.00 | - + |
| 39 | 20-11-153 | Thrust Finger | 1 | 13 | £30.00 | - + |
| 40 | 690330 | Nut, Nyloc, 1/4" UNC | 2 | 13 | £30.00 | - + |
| 41 | 690327 | Socket Grubscrew, 1/4" UNC × 3/4" | 2 | 19 | £30.00 | - + |
| 42 | 20-41-123 | Fitted Capscrew, 3/8" UNF × 1 7/8" | 2 | 10 | £30.00 | - + |
| 43 | 125594 | Nut, Nyloc, Thin, 3/8" UNF | 7 | 11 | £30.00 | - + |
| 44 | 20-41-124 | Fitted Capscrew, 3/8" UNF × 1 9/16" | 7 | 6 | £30.00 | - + |
| 45 | 20-41-127 | Ventilator | 1 | 4 | £30.00 | - + |
| 46 | 119501 | Fibre Washer, for 1/4" BSP | 1 | 4 | £30.00 | - + |
| 47 | 123115 | Nut, Nyloc, 5/16" UNF | 12 | 17 | £30.00 | - + |
| 48 | 119471 | Plain Washer, 5/16" | 12 | 15 | £30.00 | - + |
Clutch & Housing
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 50029 | CLUTCH ASSEMBLY COMPLETE | 1 | 14 | £30.00 | - + | |
| 74363 | CLUTCH ASSEMBLY COMPLETE | 1 | 20 | £30.00 | - + | |
| 1 | 56091 | Housing, Clutch (Centre Change only) | 1 | 12 | £30.00 | - + |
| 2 | 51297 | Housing, Clutch (Remote Change only) | 1 | 18 | £30.00 | - + |
| 3 | 119482 | Washers, Spring, 3/8in. | 9 | 7 | £30.00 | - + |
| 4 | 119403 | Nut, Plain, 3/8in. BSF | 9 | 4 | £30.00 | - + |
| 5 | 51310 | Fork, Clutch Operating | 1 | 5 | £30.00 | - + |
| 6 | 122097 | Bush, Oilite | 1 | 5 | £30.00 | - + |
| 7 | 75242 | Distance Piece | 1 | 6 | £30.00 | - + |
| 8 | 111938 | Bolt, 3/8in. BSF | 1 | 12 | £30.00 | - + |
| 9 | 77537 | Distance Collar | 1 | 7 | £30.00 | - + |
| 10 | 119482 | Washer, Spring, 3/8in. | 1 | 14 | £30.00 | - + |
| 11 | 119403 | Nut, Plain, 3/8in. BSF | 1 | 6 | £30.00 | - + |
| 12 | 51313 | Spring, Return | 1 | 9 | £30.00 | - + |
| 13 | 119227 | Bolt, 5/16in. BSF | 10 | 14 | £30.00 | - + |
| 14 | 111902 | Washer, Thackeray, 5/16in. | 13 | 16 | £30.00 | - + |
| 15 | 119402 | Nut, Plain, 5/16in. BSF | 13 | 12 | £30.00 | - + |
| 16 | 51340 | Bush, Engaging and Selector Shafts | 3 | 1 | £30.00 | - + |
| 17 | 52182 | Bush, Bearing Bracket | 1 | 16 | £30.00 | - + |
| 18 | 51303 | Shaft, Selector | 1 | 16 | £30.00 | - + |
| 19 | 51304 | Fork, Selector Shaft | 1 | 6 | £30.00 | - + |
| 20 | 112109 | Grubscrew, Socket, 2BA | 1 | 14 | £30.00 | - + |
| 21 | 51301 | Lever, Selector, Shaft Engaging | 1 | 2 | £30.00 | - + |
| 22 | 51300 | Shaft, Engaging | 1 | 19 | £30.00 | - + |
| 23 | 51298 | Bracket, Bearing Engaging Shaft | 1 | 7 | £30.00 | - + |
| 24 | 51211 | Spring, Neutral Location | 1 | 4 | £30.00 | - + |
| 25 | 51210 | Plunger, Neutral Location | 1 | 15 | £30.00 | - + |
| 26 | 119604 | Key, Woodruff | 1 | 9 | £30.00 | - + |
| 27 | 51302 | Lever, Engaging Shaft Oper. | 1 | 8 | £30.00 | - + |
| 28 | 119472 | Washer, Plain, 3/8in. | 1 | 6 | £30.00 | - + |
| 29 | 119403 | Nut, Plain, 3/8in. BSF | 1 | 16 | £30.00 | - + |
| 30 | 119480 | Washer, Spring, 1/4in. | 2 | 10 | £30.00 | - + |
| 31 | 119201 | Bolt, 1/4in. BSF | 2 | 6 | £30.00 | - + |
| 32 | 51307 | Pin, Pivot, Selector Lever | 1 | 13 | £30.00 | - + |
| 33 | 112109 | Grubscrew, Socket, 2BA | 1 | 14 | £30.00 | - + |
| 34 | 51305 | Lever, Selector | 1 | 14 | £30.00 | - + |
| 35 | 52183 | Bush, Selector Lever | 1 | 14 | £30.00 | - + |
| 36 | 119472 | Washer, Plain, 3/8in. | 1 | 16 | £30.00 | - + |
| 37 | 119524 | Pin, Split, 1/16in. | 1 | 3 | £30.00 | - + |
| 38 | 51308 | Pin, Clevis | 1 | 19 | £30.00 | - + |
| 39 | 119470 | Washer, Plain, 1/4in. | 2 | 18 | £30.00 | - + |
| 40 | 111934 | Pin, Split, 1/16in. | 2 | 13 | £30.00 | - + |
| 41 | 71621 | Cover | 1 | 2 | £30.00 | - + |
| 42 | 51309 | Cover | 1 | 10 | £30.00 | - + |
| 43 | 111894 | Setscrew, 2 BA | 4 | 15 | £30.00 | - + |
| 45 | 74889 | Spring, Thrust, White | 9 | 10 | £30.00 | - + |
| 46 | 74890 | Plate, Release Lever | 1 | 9 | £30.00 | - + |
| 47 | 74891 | Spring, Release Lever retaining | 3 | 19 | £30.00 | - + |
| 48 | 74892 | Spring, Anti-Rattle | 3 | 11 | £30.00 | - + |
| 49 | 74893 | Nut, Eyebolt | 3 | 6 | £30.00 | - + |
| 50 | 74894 | Pin, Release Lever | 3 | 20 | £30.00 | - + |
| 51 | 74895 | Eyebolt | 3 | 18 | £30.00 | - + |
| 52 | 74896 | Strut | 3 | 4 | £30.00 | - + |
| 53 | 74897 | Release Lever | 3 | 12 | £30.00 | - + |
| 54 | 74848 | COVER ASSEMBLY | 1 | 9 | £30.00 | - + |
| 53186 | Cover | 3 | 4 | £30.00 | - + | |
| 55 | 74899 | Pressure Plate | 1 | 11 | £30.00 | - + |
| 56 | 50284 | Release Bearing & Spring Assembly | 1 | 12 | £30.00 | - + |
| 58 | 50286 | Spring, Retaining | 2 | 5 | £30.00 | - + |
| 59 | 50283 | DRIVEN PLATE ASSEMBLY | 1 | 1 | £30.00 | - + |
| 74904 | Facing, Package, Driven Plate | 1 | 13 | £30.00 | - + | |
| 60 | 119222 | Bolt, 5/16in. BSF x 1in. | 6 | 2 | £30.00 | - + |
| 61 | 119481 | Washer, Spring, 5/16in. | 6 | 20 | £30.00 | - + |
Cooling System
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-32-001 | Radiator Assembly | 1 | 11 | £30.00 | - + |
| 2 | - | Drain Plug, 1/4" BSP | 2 | 17 | £30.00 | - + |
| 3 | 119501 | Fibre Washer, For 1/4" BSP | 2 | 10 | £30.00 | - + |
| - | 20-32-136 | Fan Shield | 1 | 2 | £30.00 | - + |
| - | 20-32-137 | Stay - Fan Shield | 2 | 3 | £30.00 | - + |
| - | 110799 | Setscrew, 2 BA × 1/2" Rd. Hd. Chromed | 8 | 4 | £30.00 | - + |
| - | 122442 | Plain Washer, 3/16", Chromed | 8 | 19 | £30.00 | - + |
| - | 122315 | Nut, Nyloc, 2 BA | 4 | 11 | £30.00 | - + |
| - | 111109 | Plain Nut, 2 BA | 4 | 3 | £30.00 | - + |
| 4 | 20-32-111 | Fan Cowl | 1 | 18 | £30.00 | - + |
| 5 | 20-32-112 | Tapping Strip | 2 | 2 | £30.00 | - + |
| 6 | 112138 | Setscrew, 2 BA × 3/16" C'sk. Hd. | 4 | 11 | £30.00 | - + |
| 7 | 110799 | Setscrew, 2 BA × 1/2" Rd. Hd. Chromed | 8 | 8 | £30.00 | - + |
| 8 | 119488 | Spring Washer, 3/16" | 8 | 15 | £30.00 | - + |
| 9 | 20-32-113 | Bracket, Radiator Mounting | 2 | 11 | £30.00 | - + |
| 10 | 690050 | Setscrew, 1/4" UNF × 3/4" Hex. Hd. | 4 | 11 | £30.00 | - + |
| 11 | 119480 | Spring Washer, 1/4" | 4 | 4 | £30.00 | - + |
| 12 | 119470 | Plain Washer, 1/4" | 4 | 11 | £30.00 | - + |
| 13 | 125566 | Nut, Avlok, 1/4" UNF | 4 | 7 | £30.00 | - + |
| 14 | 20-32-114 | Mounting Rubber, Side | 2 | 19 | £30.00 | - + |
| 15 | 20-32-115 | Mounting Rubber, Bottom | 2 | 6 | £30.00 | - + |
| 16 | 123113 | Nut, Nyloc, 3/8" UNF | 4 | 19 | £30.00 | - + |
| 17 | 20-32-120 | Header Tank | 1 | 17 | £30.00 | - + |
| 18 | 20-32-135 | Cap - Header Tank | 1 | 11 | £30.00 | - + |
| 19 | 20-32-140 | Washer - Header Tank Cap | 1 | 13 | £30.00 | - + |
| 20 | 20-32-121 | Packing Piece - Header Tank Mounting | 3 | 16 | £30.00 | - + |
| 21 | 123130 | Setscrew, 1/4" UNF × 5/8" Hex. Hd. | 2 | 15 | £30.00 | - + |
| 22 | 119480 | Spring Washer, 1/4" | 2 | 7 | £30.00 | - + |
| 23 | 119470 | Plain Washer, 1/4" | 3 | 7 | £30.00 | - + |
| 24 | 123116 | Nut, Nyloc, 1/4" UNF | 1 | 7 | £30.00 | - + |
| 25 | 20-32-122 | Thermostat Elbow | 1 | 15 | £30.00 | - + |
| 26 | 119470 | Plain Washer, 1/4" | 4 | 10 | £30.00 | - + |
| 27 | 123116 | Nut, Nyloc, 1/4" UNF | 4 | 7 | £30.00 | - + |
| 28 | 20-32-123 | Filler Pipe | 1 | 5 | £30.00 | - + |
| 29 | 20-32-124 | Clip - Filler Pipe | 2 | 3 | £30.00 | - + |
| 30 | 112121 | Screw, 2 BA × 1/2" Rd. Hd. | 2 | 19 | £30.00 | - + |
| 31 | 122315 | Nut, Nyloc. 2 BA | 2 | 14 | £30.00 | - + |
| 32 | 20-32-119 | Elbow Pipe | 1 | 11 | £30.00 | - + |
| 33 | 20-32-126 | Hose - Header Tank to Filler Pipe | 1 | 10 | £30.00 | - + |
| 34 | 20-32-125 | Hose - Filler Pipe to Elbow Pipe | 1 | 3 | £30.00 | - + |
| 35 | 690358 | Hose Clip, No. 1 | 4 | 17 | £30.00 | - + |
| 36 | 20-32-117 | Elbow Hose - Radiator to Elbow Pipe | 1 | 8 | £30.00 | - + |
| 37 | 20-32-118 | Hose - Elbow Pipe to Water Pump Inlet | 1 | 16 | £30.00 | - + |
| 38 | 20-32-116 | Hose - Thermostat Elbow to Radiator | 1 | 16 | £30.00 | - + |
| 39 | 113445 | Hose Clip, No. 2 | 6 | 20 | £30.00 | - + |
| 40 | 690462 | Overflow Pipe | 1 | 16 | £30.00 | - + |
| 41 | 13489 | Wire, Copper | A/R | 1 | £30.00 | - + |
| 42 | 20-06-141 | Water Hose Adaptor, 3/8" BSP | 5 | 12 | £30.00 | - + |
| 43 | 119500 | Fibre Washer, For 3/8" BSP | 5 | 19 | £30.00 | - + |
| 44 | 20-05-121 | By-Pass Pipe | 1 | 15 | £30.00 | - + |
| 45 | 20-32-128 | Heater Pipe - Thermostat Housing to Water Valve | 1 | 10 | £30.00 | - + |
| 46 | 20-32-129 | Heater Pipe - Water Valve to Heater | 1 | 7 | £30.00 | - + |
| 47 | 20-32-130 | Heater Pipe - Heater to Thermostat Housing | 1 | 11 | £30.00 | - + |
| 48 | 20-32-132 | Clip - Heater Pipes | 2 | 20 | £30.00 | - + |
| 49 | 20-32-127 | Hose - Thermostat Elbow to Header Tank | 1 | 19 | £30.00 | - + |
| 50 | 20-05-122 | Hose, Connector | 5 | 2 | £30.00 | - + |
| 51 | 20-32-134 | Elbow Hose - Thermostat Pipe to Water Valve | 1 | 17 | £30.00 | - + |
| 52 | 20-32-131 | Elbow Hose - Water Valve Pipe to Heater | 1 | 19 | £30.00 | - + |
| 53 | 20-32-133 | Hose - Heater to Return Pipe | 1 | 14 | £30.00 | - + |
| 54 | 110883 | Hose Clip, No. 00 | 18 | 20 | £30.00 | - + |
| - | 20-32-138 | Radiator Bllind Complete | 1 | 17 | £30.00 | - + |
| - | 20-32-700 | Frame - Radiator Blind | 1 | 6 | £30.00 | - + |
| - | 20-32-701 | Blind Leather Cloth And Roller | 1 | 13 | £30.00 | - + |
| - | 20-32-702 | Rod for Blind | 1 | 19 | £30.00 | - + |
| - | 20-32-703 | Cable, Inner, 84" | 1 | 17 | £30.00 | - + |
| - | 20-32-704 | Cable, Outer, 52" | 1 | 8 | £30.00 | - + |
| - | 20-32-705 | Grommet | 1 | 6 | £30.00 | - + |
| - | 20-32-706 | Cable Abutment | 1 | 4 | £30.00 | - + |
| - | 20-32-707 | Control Box | 1 | 6 | £30.00 | - + |
| - | 20-32-708 | Ball Chain and Brass Connector | 1 | 9 | £30.00 | - + |
| - | 20-32-709 | "U" Cllip | 1 | 19 | £30.00 | - + |
| - | 20-32-710 | Split Ring | 1 | 15 | £30.00 | - + |
| - | 20-32-711 | Cable Clip | 1 | 13 | £30.00 | - + |
| - | 690571 | Screw, PK No. 8 × 5/8", Type N | 6 | 11 | £30.00 | - + |
| - | 690572 | Screw, PK No. 8 × 5/8" Type N | 5 | 1 | £30.00 | - + |
Crankshaft
Cylinder Head
Dashboard
DB2 & DB2_4 MKI & MKII
DB4
Electrical and Instruments
Electrical Units
Electrical, Lamps, Switches and Control Boxes
Electrical, Windscreen Wipers, Horns, Trafficator
Engine
Engine Crankshaft
Engine Cylinder Block
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | f8f6bdc08673 | CYLINDER BLOCK | 1 | 20 | £30.00 | - + |
| 46c3b4cb5691 | CYLINDER BLOCK | 1 | 15 | £30.00 | - + | |
| 2 | d7c75c01bbb2 | Joint, Cylinder Liner. (.009in.) | 6 | 2 | £30.00 | - + |
| 7912a48e8338 | Joint, Cylinder Liner. (.012in.) | 6 | 14 | £30.00 | - + | |
| 110989309ea5 | Joint, Cylinder Liner. (.014in.) | 6 | 20 | £30.00 | - + | |
| 41a7a6474273 | Joint, Cylinder Liner. (.015in.) | 6 | 12 | £30.00 | - + | |
| f4537171b6e5 | Joint, Cylinder Liner. (.017in.) | 6 | 2 | £30.00 | - + | |
| e37c31d9c611 | Joint, Cylinder Liner. (.024in.) | 6 | 19 | £30.00 | - + | |
| 74dfe870b596 | Joint, Cylinder Liner. (.004in.) | 6 | 4 | £30.00 | - + | |
| d6602ac88cb4 | Joint, Cylinder Liner. (.006in.) | 6 | 20 | £30.00 | - + | |
| 5b81df530708 | Joint, Cylinder Liner. (.009in.) | 6 | 2 | £30.00 | - + | |
| c045d6db2c5d | Joint, Cylinder Liner. (.012in.) | 6 | 7 | £30.00 | - + | |
| 11bb1d15f989 | Joint, Cylinder Liner. (.014in.) | 6 | 10 | £30.00 | - + | |
| 3 | 86aa204e8637 | LINER, Cylinder | 6 | 1 | £30.00 | - + |
| 8d89944a71e6 | LINER, Cylinder | 6 | 13 | £30.00 | - + | |
| 4 | 171cc78dc262 | Plug, Core 1/2in. BSF | 2 | 4 | £30.00 | - + |
| 5 | 7995a6c4c3a5 | Plug, Core 3/4in. BSF | 1 | 15 | £30.00 | - + |
| 6 | 250572386e18 | Plug, Core 3/8in. BSF | 1 | 14 | £30.00 | - + |
| 7 | 916d0cd014a4 | Plug, Core 1/4in. BSF | 1 | 16 | £30.00 | - + |
| 8 | ad2c36872f45 | Plug, Welch, 1in. dia. | 2 | 3 | £30.00 | - + |
| 9 | 0eb0f5ca3436 | Bolt, Oil Transfer, Main Bearing | 2 | 14 | £30.00 | - + |
| 10 | ab82312feeeb | Bolt, Oil Transfer, Rear Main Bearing | 1 | 1 | £30.00 | - + |
| 11 | 3fb7f4c51e4b | Plug, Oil, Crankcase | 1 | 20 | £30.00 | - + |
| 12 | a87a32d4fdb4 | Washer, Oil Transfer Bolt and Oil Plug | 4 | 19 | £30.00 | - + |
| 13 | 3e248995c5c7 | VALVE, Relief | 1 | 20 | £30.00 | - + |
| 14 | ae00116975bf | Spring, Relief Valve | 1 | 17 | £30.00 | - + |
| 15 | 5ee02b974fb0 | Plug, Relief Valve | 1 | 20 | £30.00 | - + |
| 16 | b81322a3e039 | Washer, Relief Valve Plug | 1 | 15 | £30.00 | - + |
| 17 | 3324bbddd28e | Dowel, Locating, Main Brg. Hsg. | 2 | 5 | £30.00 | - + |
| 18 | dd383c02ed27 | Dowel Timing Case | 2 | 15 | £30.00 | - + |
| 19 | bf9281e2d923 | Plug, Drain, Cylinder Block | 1 | 19 | £30.00 | - + |
| 20 | 4d97080fe467 | Washer, Cylinder Block Drain Plug | 1 | 7 | £30.00 | - + |
| 21 | 60e0d8dd1458 | Top, Drain | 1 | 12 | £30.00 | - + |
| 22 | 419cc922fce0 | Washer, Fibre, 1/2in. Gas | 1 | 6 | £30.00 | - + |
| 23 | 31459fd1bf7f | Plug, 1/2in. Gas, Hex. Hd. | 1 | 18 | £30.00 | - + |
| 24 | 2c16f81a53b6 | Washer, Fibre, 1/2in. Gas | 1 | 13 | £30.00 | - + |
| 25 | c1a283a40179 | Stud, 1/4in. BSF x 1in. | 2 | 2 | £30.00 | - + |
| 26 | 482ba3bf3274 | Washer, Spring 1/4in. | 4 | 17 | £30.00 | - + |
| 27 | 7fcc3b7e465c | Nut, Plain, 1/4in. BSF | 4 | 17 | £30.00 | - + |
| 28 | 4a36a43197f3 | Setscrew, 1/4in. BSF x 3/4in. | 1 | 20 | £30.00 | - + |
| 29 | 51b325efd85b | Washer, Plain, 1/4in. | 1 | 12 | £30.00 | - + |
| 30 | f37f305dd68c | Stud, 1/4in. BSF x 13/16in. | 2 | 19 | £30.00 | - + |
| 31 | d1043b578fd2 | Gasket | 1 | 13 | £30.00 | - + |
| 32 | bb1c87003e73 | Cover, plate | 1 | 11 | £30.00 | - + |
| 33 | de29180e8a1c | Washer, Spring | 2 | 1 | £30.00 | - + |
| 34 | 96b5023f5c52 | Nut, Plain, 1/4in. BSF | 2 | 8 | £30.00 | - + |
| 35 | f78b641ce175 | Stud, Cylinder Head (VB6J 10 only) | 14 | 3 | £30.00 | - + |
| 36 | fd61630203e6 | Stud, 1/4in. BSF x 2.1/8in. | 3 | 8 | £30.00 | - + |
| 48f368e044a3 | Stud, 1/4in. BSF x 1.7/8in. | 1 | 11 | £30.00 | - + | |
| 1e8abc375d31 | Stud, 1/4in. BSF x 1.1/8in. | 2 | 12 | £30.00 | - + | |
| 37 | 2c8ae206894b | Bush, Water Pump Drive Spindle | 1 | 12 | £30.00 | - + |
| 38 | 2f7622a4ef8c | Bush, Oil Pump Gear Shaft | 1 | 13 | £30.00 | - + |
| 39 | 3ec3735347e8 | Plug, Oil Restrictor | 1 | 5 | £30.00 | - + |
| 40 | 92086cf413f8 | DIPSTICK | 1 | 4 | £30.00 | - + |
| 4df5b047b151 | Rubber Ring to Restrictor | 1 | 18 | £30.00 | - + |
Engine Cylinder Head
Engine Electrical
Engine Inlet and Exhaust Manifolds and Carburetors and Air Filters
Engine Lower Timing Case
Engine Mountings
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-10-112 | Engine Bearer Bracket | 2 | 11 | £30.00 | - + |
| - | 20-10-002 | Engine Bearer Bracket Assembly | 2 | 10 | £30.00 | - + |
| 2 | 119471 | Plain Washer, 5/16" | 8 | 19 | £30.00 | - + |
| 3 | 123115 | Nut, Nyloc, 5/16" UNF | 8 | 9 | £30.00 | - + |
| 4 | 20-10-120 | Engine Front Mounting | 2 | 20 | £30.00 | - + |
| 5 | 20-10-116 | Shim - Engine Mounting | A/R | 15 | £30.00 | - + |
| - | 25-10-181 | Shim - Engine Mounting | A/R | 8 | £30.00 | - + |
| 6 | 119472 | Plain Washer, 3/8" | 4 | 3 | £30.00 | - + |
| 7 | 123113 | Nut, Nyloc, 3/8" UNF | 2 | 2 | £30.00 | - + |
| 8 | 125594 | Nut, Nyloc, Thin. 3/8" UNF | 2 | 10 | £30.00 | - + |
| 9 | 20-10-113 | Engine Front Mounting Bracket | 2 | 9 | £30.00 | - + |
| 10 | 125519 | Setscrew, 5/16" UNF × 5/8" | 8 | 1 | £30.00 | - + |
| 11 | 119481 | Spring Washer, 5/16" | 8 | 8 | £30.00 | - + |
| 12 | 119471 | Plain Washer, 5/16" | 8 | 10 | £30.00 | - + |
| 13 | 20-10-117 | Rebound Bracket (see item 1. Used with 20-10-112) | 2 | 3 | £30.00 | - + |
| - | 20-10-174 | Rebound Bracket (see item 1. Used with 20-10-002) | 2 | 19 | £30.00 | - + |
| 14 | 125520 | Setscrew, 5/16" UNF × 1/2" | 6 | 18 | £30.00 | - + |
| 15 | 119481 | Spring Washer, 5/16" | 6 | 14 | £30.00 | - + |
| 16 | 20-10-118 | Rebound Rubber | 6 | 1 | £30.00 | - + |
| 17 | 20-10-119 | Shim - Rebound Rubber | A/R | 10 | £30.00 | - + |
| 18 | 20-10-121 | Shim - Rebound Rubber | A/R | 4 | £30.00 | - + |
| 19 | 119472 | Plain Washer, 3/8" | 2 | 9 | £30.00 | - + |
| 20 | 125594 | Nut, Nyloc, Thin. 3/8" UNF | 2 | 13 | £30.00 | - + |
| - | 25-10-006 | Engine Bearer Bracket Assembly - R.H. | 1 | 10 | £30.00 | - + |
| - | 25-10-007 | Engine Bearer Bracket Assembly - L.H. | 1 | 1 | £30.00 | - + |
| - | 23-10-008 | Adaptor Plate | 2 | 20 | £30.00 | - + |
| - | 23-10-190 | Mounting Bracket | 1 | 6 | £30.00 | - + |
| - | 23-10-191 | Distance Piece | 1 | 1 | £30.00 | - + |
| - | 23-10-192 | Engine Damper | 1 | 2 | £30.00 | - + |
| - | UFB/106/20R | Bolt | 1 | 8 | £30.00 | - + |
| - | UFB/106/28R | Bolt | 1 | 13 | £30.00 | - + |
| - | 125594 | Nut | 2 | 9 | £30.00 | - + |
| - | 690919 | Special Washer | 5 | 7 | £30.00 | - + |
| - | 42-10-192 | Engine Washer | 1 | 12 | £30.00 | - + |
| - | 48-10-009 | Fixing Plate Assembly | 2 | 7 | £30.00 | - + |
| - | 123115 | Nut, Nyloc | 12 | 17 | £30.00 | - + |
| - | UFS/107/7R | Setscrew | 4 | 12 | £30.00 | - + |
| - | 119483 | Setscrew | 4 | 11 | £30.00 | - + |
| - | UFS/105/7R | Setscrew | 4 | 16 | £30.00 | - + |
| - | 119481 | Spring Washer | 4 | 1 | £30.00 | - + |
| - | 119471 | Plain Washer | 4 | 9 | £30.00 | - + |
| 21 | 20-10-055 | Engine Rear Mounting Bracket Assembly | 1 | 8 | £30.00 | - + |
| 22 | 123131 | Bolt, 5/16" UNF × 1" | 4 | 4 | £30.00 | - + |
| 23 | 119471 | Plain Washer, 5/16" | 4 | 17 | £30.00 | - + |
| 24 | 123115 | Nut, Nyloc, 5/16" UNF | 4 | 12 | £30.00 | - + |
| 25 | 690405 | Stud. 5/16" UNC/UNF × 2 7/8" | 2 | 20 | £30.00 | - + |
| 26 | 20-10-165 | Distance Tube | 2 | 19 | £30.00 | - + |
| 27 | 119471 | Plain Washer, 5/16" | 2 | 18 | £30.00 | - + |
| 28 | 123115 | Nut, Nyloc, 5/16" UNF | 2 | 5 | £30.00 | - + |
| 29 | 20-10-164 | Engine Rear Mounting | 2 | 9 | £30.00 | - + |
| - | 20--10-176 | Tightening Ring Assembly | 2 | 15 | £30.00 | - + |
| - | 23-10-179 | Mounting Plate | 2 | 3 | £30.00 | - + |
| 30 | 20-10-166 | Shim - Engine Mounting | 2 | 12 | £30.00 | - + |
| 31 | 119472 | Plain Washer, 3/8" | 2 | 12 | £30.00 | - + |
| 32 | 123113 | Nut, Nyloc, 3/8" UNF | 2 | 3 | £30.00 | - + |
| 33 | 20-10-057 | Strut Assembly | 1 | 3 | £30.00 | - + |
| 34 | 20-10-172 | Forward Lug | 1 | 16 | £30.00 | - + |
| 35 | 122482 | Locknut, 5/16" UNF | 2 | 3 | £30.00 | - + |
| 36 | 690407 | Special Washer, 5/16" | 4 | 20 | £30.00 | - + |
| 37 | 20-10-173 | Distance Tube | 2 | 14 | £30.00 | - + |
| 38 | 20-34-118 | Rubber Bush | 4 | 19 | £30.00 | - + |
| 39 | 123115 | Nut, Nyloc, 5/16" UNF | 2 | 19 | £30.00 | - + |
Engine Oil Filter & Electrical Accessories
Engine Oil Sump and Timing Case Top
Exhaust System
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-35-701 | Exhaust System Assembly - Front | 1 | 10 | £30.00 | - + |
| 2 | 20-35-702 | Exhaust System Assembly - Rear | 1 | 20 | £30.00 | - + |
| 3 | 690024 | Plain Nut, 5/16" UNF, Selfinuzed | 6 | 10 | £30.00 | - + |
| 4 | 119481 | Spring Washer, 5/16" | 6 | 15 | £30.00 | - + |
| 5 | 20-35-126 | Clamp Bar - Upper | 1 | 15 | £30.00 | - + |
| 6 | 20-35-124 | Strap - Exhaust Down Pipes | 1 | 19 | £30.00 | - + |
| 7 | 20-35-125 | Clamp Bar - Upper | 1 | 20 | £30.00 | - + |
| 8 | 690108 | Bolt, 1/4" UNF × 1 1/2" | 1 | 1 | £30.00 | - + |
| 9 | 119480 | Spring Washer,. 1/4" | 1 | 13 | £30.00 | - + |
| 10 | 125557 | Plain Nut, 5/16" UNF | 8 | 3 | £30.00 | - + |
| 11 | 119481 | Spring Washer, 5/16" | 8 | 8 | £30.00 | - + |
| 12 | 20-35-129 | Clamp Plate | 16 | 10 | £30.00 | - + |
| 13 | 20-35-127 | Rubber Sling - Exhaust Pipes | 2 | 12 | £30.00 | - + |
| 14 | 20-35-130 | Spacer - Exhaust Pipe Sling | 8 | 1 | £30.00 | - + |
| 15 | 690051 | Bolt, 5/16" UNF × 1 1/2" | 8 | 8 | £30.00 | - + |
| 16 | 20-35-131 | Insulator - Exhaust Pipe Sling | 4 | 19 | £30.00 | - + |
| 17 | 20-35-132 | U-Bolt, 1/4" UNF | 4 | 19 | £30.00 | - + |
| 18 | 20-35-133 | Clamp Bracket | 4 | 2 | £30.00 | - + |
| 19 | 20-35-136 | Tie Plate | 2 | 9 | £30.00 | - + |
| 20 | 119480 | Spring Washer, 1/4" | 8 | 2 | £30.00 | - + |
| 21 | 125583 | Plain Nut, 1/4" UNF | 8 | 11 | £30.00 | - + |
| 22 | 20-35-128 | Rubber Sling - Silencers | 2 | 16 | £30.00 | - + |
| 23 | 48-35-003 | Exhaust Silencer Assembly | 2 | 4 | £30.00 | - + |
| 23a | 20-35-118 | Pipe - Intermediate - Front | 1 | 5 | £30.00 | - + |
| 23b | 20-35-119 | Pipe - Intermediate - Rear | 1 | 13 | £30.00 | - + |
| 24 | 20-35-123 | Tail Pipe | 2 | 3 | £30.00 | - + |
| 25 | 20-35-007 | Shield Assembly - Front Floor | 1 | 9 | £30.00 | - + |
| 26 | 690453 | Screw, PK No. 10 × 3/4" Mush, Hd. | 6 | 6 | £30.00 | - + |
| 27 | 20-35-145 | Distance Tube, 3/16" | 1 | 14 | £30.00 | - + |
| 28 | 113441 | Bolt, 2 BA × 1" | 1 | 11 | £30.00 | - + |
| 29 | 20-35-006 | Shield Assembly - Rear Floor | 1 | 8 | £30.00 | - + |
| 30 | 119496 | Plain Washer - 3/16" | 9 | 20 | £30.00 | - + |
| 31 | 122315 | Nut, Nyloc, 2 BA | 2 | 7 | £30.00 | - + |
| 32 | 20-35-005 | Shield Assembly - Rear Seat Pan | 1 | 17 | £30.00 | - + |
| 33 | 690384 | Bolt, 2 BA × 3/8" | 2 | 12 | £30.00 | - + |
| 34 | 690150 | Spacing Washer, 1/4" | 4 | 20 | £30.00 | - + |
| 35 | 119480 | Spring Washer, 1/4" | 4 | 7 | £30.00 | - + |
| 36 | 1233127 | Bolt, 1/4" UNF × 3/4" | 4 | 1 | £30.00 | - + |
Exhaust System and Spare Wheel Tray
Foot Controls
Frame & Fittings Engine Mountings
Front Brakes
Front Bulkhead
Front Suspension
Front Suspension Cross Member Assembly, Bell Crank
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 55072 | CENTRE SECTION | 1 | 8 | £30.00 | - + |
| 2 | 119591 | Plug, 1/8in. BSP | 2 | 17 | £30.00 | - + |
| 3 | 119504 | Washer, Fibre | 2 | 13 | £30.00 | - + |
| 4 | 119590 | Plug, 3/8in. BSP | 1 | 4 | £30.00 | - + |
| 5 | 119500 | Washer, Fibre | 1 | 20 | £30.00 | - + |
| 6 | 55073 | Bracket, Rad. And Bell Crank | 1 | 18 | £30.00 | - + |
| 7 | 55076 | Spindle | 1 | 16 | £30.00 | - + |
| 8 | 55078 | Distance Piece, Upper | 1 | 10 | £30.00 | - + |
| 9 | 113421 | Bearing, Needle Roller | 2 | 12 | £30.00 | - + |
| 10 | 55079 | Washer, Thrust, Spindle | 2 | 19 | £30.00 | - + |
| 11 | 55077 | Distance Piece, Lower | 1 | 13 | £30.00 | - + |
| 12 | 113428 | Circlip, Bell Crank Spindle | 1 | 7 | £30.00 | - + |
| 13 | 113419 | Seal, Oil, Bell Crank Spindle | 1 | 5 | £30.00 | - + |
| 14 | 55075 | Lever, Bell Crank, (RHD) | 1 | 11 | £30.00 | - + |
| 58655 | Lever, Bell Crank, (RHD) | 1 | 1 | £30.00 | - + | |
| 56250 | Lever, Bell Crank, (LHD) | 1 | 9 | £30.00 | - + | |
| 15 | 119474 | Washer, Plain, 1/2in. | 1 | 8 | £30.00 | - + |
| 16 | 119454 | Nut, Slotted, 1/2in. BSF | 1 | 2 | £30.00 | - + |
| 17 | 119530 | Pin, Split, 3/32in. X 1.1/4in. | 1 | 3 | £30.00 | - + |
| 18 | 113413 | Stud, 1/4in. BSF x 1.1/4in. | 2 | 19 | £30.00 | - + |
| 19 | 55081 | Shim, Bell Crank | 1 | 8 | £30.00 | - + |
| 20 | 55080 | Cover, Bell Crank | 1 | 12 | £30.00 | - + |
| 21 | 119470 | Washer, Plain, 1/4in. | 2 | 19 | £30.00 | - + |
| 22 | 113480 | Nut, Simmonds, 1/4in. BSF | 2 | 4 | £30.00 | - + |
| 23 | 119233 | Bolt, 5/16in. BSF x 2.3/4in. | 4 | 19 | £30.00 | - + |
| 24 | 119471 | Washer, Plain, 5/16in. | 4 | 13 | £30.00 | - + |
| 25 | 113410 | Nut, Simmonds, 15/16in. BSF | 4 | 18 | £30.00 | - + |
| 26 | 55083 | OUTER SECTION, Cross Member | 2 | 4 | £30.00 | - + |
| 27 | 113414 | Bearing, Needle Roller | 2 | 18 | £30.00 | - + |
| 28 | 55087 | Washer, Oil Seal | 2 | 10 | £30.00 | - + |
| 29 | 55612 | Ring, Oil Seal | 2 | 3 | £30.00 | - + |
| 30 | 55088 | Ring, Retainer, Oil Seal | 2 | 6 | £30.00 | - + |
| 31 | 55084 | Shaft, Trailing Link | 2 | 10 | £30.00 | - + |
| 32 | 119115 | Bearing, Ball | 2 | 3 | £30.00 | - + |
| 33 | 113429 | Circlip | 2 | 3 | £30.00 | - + |
| 34 | 55085 | Nut, Inner, Trailing Link Shaft | 2 | 15 | £30.00 | - + |
| 35 | 55086 | Tab, Locking, Inner Nut | 2 | 20 | £30.00 | - + |
| 36 | 111894 | Setscrew, 2BA x 3/8in. Ch. Hd. | 2 | 3 | £30.00 | - + |
| 37 | 55001 | Link, Trailing | 2 | 18 | £30.00 | - + |
| 38 | 55082 | Spigot Tube, Outer and Centre Sections | 2 | 16 | £30.00 | - + |
| 39 | 75840 | Shim .005in. | As req'd | 9 | £30.00 | - + |
| 75841 | Shim .010in. | As req'd | 13 | £30.00 | - + | |
| 40 | 55092 | Bolt, 1/4in. BSF | 24 | 20 | £30.00 | - + |
| 41 | 55093 | Washer, Plain | 24 | 19 | £30.00 | - + |
| 42 | 113480 | Nut, Simmonds | 24 | 5 | £30.00 | - + |
| 43 | 55089 | Bar, Anti-Roll | 1 | 14 | £30.00 | - + |
| 44 | 55091 | Washer, Lock, Outer Nut | 2 | 5 | £30.00 | - + |
| 45 | 55090 | Nut, Outer Trailing Link Shaft | 2 | 7 | £30.00 | - + |
| 46 | 55094 | BRACKET, Angle | 2 | 5 | £30.00 | - + |
| 47 | 119255 | Bolt, 3/8in. BSF x 3.1/2in. | 8 | 19 | £30.00 | - + |
| 48 | 119472 | Washer, Plain, 3/8in. | 8 | 12 | £30.00 | - + |
| 49 | 113411 | Nut, Simmonds | 8 | 12 | £30.00 | - + |
| 50 | 119252 | Bolt, 3/8in. x 2.3/4in. | 6 | 1 | £30.00 | - + |
| 51 | 119472 | Washer, Plain | 6 | 9 | £30.00 | - + |
| 52 | 113411 | Nut, Simmonds | 6 | 4 | £30.00 | - + |
| 53 | 55096 | Packing Piece, Frame | 2 | 10 | £30.00 | - + |
| 54 | 111993 | Bolt, 3/8in. BSF x 5.3/4in. | 8 | 16 | £30.00 | - + |
| 55 | 77570 | SHOCK ABSORBER, N/S | 1 | 5 | £30.00 | - + |
| 77571 | SHOCK ABSORBER, O/S | 1 | 16 | £30.00 | - + | |
| 56 | 57027 | Bracket, Aux. Trailing Link O/S | 1 | 10 | £30.00 | - + |
| 57029 | Bracket, Aux. Trailing Link N/S | 1 | 15 | £30.00 | - + | |
| 119472 | Washer, Plain, 3/8in. | 8 | 3 | £30.00 | - + | |
| 58 | 113411 | Nut, Simmonds | 8 | 3 | £30.00 | - + |
Front Suspension Spring Assembly, Stub Axle Carrier
Front Suspension Stub Axle, Wheel Hubs, Track Rods
Fuel System
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-34-001 | Fuel Tank Assembly | 1 | 14 | £30.00 | - + |
| 2 | 20-34-102 | Indicator Unit | 1 | 7 | £30.00 | - + |
| 3 | 20-34-113 | Joint - Indicator Unit | 1 | 5 | £30.00 | - + |
| 4 | 121717 | Screw, 3 BA × 3/8" Ch. Hd. | 6 | 17 | £30.00 | - + |
| 5 | 111885 | Spring Washer, 5/32" | 6 | 7 | £30.00 | - + |
| 6 | 690425 | "O" Ring - Indicator Float | 1 | 2 | £30.00 | - + |
| 7 | 20-34-140 | Fuel Reverse Unit | 1 | 12 | £30.00 | - + |
| 8 | 20-34-114 | Joint - Fuel Reverse Unit | 1 | 2 | £30.00 | - + |
| 9 | 113442 | Screw, 2 BA × 5/8" Hex. Hd. | 2 | 1 | £30.00 | - + |
| 10 | 119488 | Spring Washer, 3/16" | 2 | 8 | £30.00 | - + |
| 11 | 119590 | Drain Plug, 3/8" BSP | 1 | 17 | £30.00 | - + |
| 12 | 119500 | Fibre Washer, for -3/8" BSP | 1 | 3 | £30.00 | - + |
| 13 | 20-34-115 | Pad - Tank Support | 2 | 1 | £30.00 | - + |
| - | 20-34-148 | Packing Felt, Wide - Tank Mounting | 1 | 6 | £30.00 | - + |
| - | 20-34-149 | Packing Felt, Long - Tank Mounting | 1 | 5 | £30.00 | - + |
| 14 | 20-34-004 | Cable Assembly - Tank Securing | 2 | 15 | £30.00 | - + |
| 15 | 119472 | Plain Washer, 3/8" | 2 | 10 | £30.00 | - + |
| 16 | 125564 | Plain Nut, 3/8" UNF | 6 | 19 | £30.00 | - + |
| 17 | 20-34-150 | End Fitting - Tank Cable | 2 | 6 | £30.00 | - + |
| 18 | 22-34-105 | Fuel Pump, Dual | 1 | 15 | £30.00 | - + |
| 19 | 20-34-139 | Rubber Sock - Fuel Pump | 2 | 8 | £30.00 | - + |
| 20 | 20-34-118 | Rubber Bush | 4 | 1 | £30.00 | - + |
| 21 | 20-34-007 | Mounting Bracket Assembly - Fuel Pump | 1 | 18 | £30.00 | - + |
| 22 | 20-34-137 | Distance Tube | 2 | 7 | £30.00 | - + |
| 23 | 690407 | Special Plain Washer | 2 | 19 | £30.00 | - + |
| 24 | 690365 | Bolt, 5/16" BSF × 1 5/16" Hex. Hd. Drillled | 2 | 15 | £30.00 | - + |
| 25 | 13489 | Locking Wire | A/R | 6 | £30.00 | - + |
| 26 | 20-34-132 | Shield - Fuel Pump | 1 | 4 | £30.00 | - + |
| 27 | 119470 | Plain Washer, 1/4" | 4 | 7 | £30.00 | - + |
| 28 | 123199 | Bolt, 1/4" UNF × 1/2" Hex. Hd. Drilled | 4 | 11 | £30.00 | - + |
| 29 | 20-34-008 | Fuel Pipe Assembly - Tank to Pump | 1 | 17 | £30.00 | - + |
| 30 | 20-34-009 | Fuel Pipe Assembly - Tank to Carburettors | 1 | 5 | £30.00 | - + |
| 31 | 122010 | Grommet | 1 | 16 | £30.00 | - + |
| 32 | 121701 | Bolt, 2 BA × 1 1/4" Hex. Hd. | 7 | 10 | £30.00 | - + |
| 33 | 20-34-119 | Clamp Block, Single Pipe | 6 | 18 | £30.00 | - + |
| 34 | 119496 | Plain Washer, 3/16" | 3 | 7 | £30.00 | - + |
| 35 | 690484 | Nut, Nyloc, 2 BA | 3 | 6 | £30.00 | - + |
| 36 | 20-34-133 | Clamp Block, Twin Pipe | 8 | 20 | £30.00 | - + |
| 37 | 20-34-134 | Clamp Strip, Short | 4 | 12 | £30.00 | - + |
| 38 | 119488 | Spring Washer, 3/16" | 4 | 14 | £30.00 | - + |
Fuel, cooling and Exhaust
Fuel, Cooling and Exhaust
Gearbox Case and Selectors
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| - | 20-41-001 | Gearbox Complete | 1 | 6 | £30.00 | - + |
| - | 21-41-001 | Gearbox Complete | 1 | 1 | £30.00 | - + |
| - | 23-41-001 | Gearbox Complete | 1 | 13 | £30.00 | - + |
| - | 23-41-050 | Gearbox Complete | 1 | 18 | £30.00 | - + |
| - | 24-41-001 | Gearbox Complete | 1 | 1 | £30.00 | - + |
| - | 24-41-050 | Gearbox Complete | 1 | 1 | £30.00 | - + |
| - | 20-41-854 | Abutment Plate Assembly | 1 | 7 | £30.00 | - + |
| 1 | 20-41-121 | Gearbox Case | 1 | 3 | £30.00 | - + |
| 2 | 114163 | Drain Plug | 1 | 11 | £30.00 | - + |
| - | 114383 | Copper Washer | 1 | 19 | £30.00 | - + |
| - | 20-41-122 | Bell Housing - See Clutch | - | 15 | £30.00 | - + |
| - | 20-41-005 | Top Cover Assembly | 1 | 14 | £30.00 | - + |
| 3 | 20-41-129 | Top Cover | 1 | 13 | £30.00 | - + |
| 4 | 20-41-130 | Selector Rod - 1st and 2nd Speed | 1 | 9 | £30.00 | - + |
| 5 | 20-41-131 | Selector Rod - 3st and 4nd Speed | 1 | 4 | £30.00 | - + |
| 6 | 20-41-132 | Selector Rod - Reverse | 1 | 15 | £30.00 | - + |
| 7 | 20-41-133 | 2nd Speed Stop | 1 | 15 | £30.00 | - + |
| 8 | 20-41-134 | 3nd Speed Stop | 1 | 11 | £30.00 | - + |
| 9 | 20-41-135 | Reverse Stop | 1 | 20 | £30.00 | - + |
| 10 | 20-41-136 | Shim - For Stops | 1 set | 18 | £30.00 | - + |
| 11 | 20-41-137 | Fork - 1st and 2nd Speed | 1 | 17 | £30.00 | - + |
| 12 | 20-41-138 | Fork - 3st and 4nd Speed | 1 | 20 | £30.00 | - + |
| 13 | 20-41-139 | Reverse Selector | 1 | 15 | £30.00 | - + |
| 14 | 20-41-140 | Pin - For Reverse Selector | 1 | 14 | £30.00 | - + |
| 15 | 20-41-141 | Setscrew - For Forks | 3 | 4 | £30.00 | - + |
| 16 | 122227 | Locking Wire, Copper 1/16" diam. | 2ft. | 16 | £30.00 | - + |
| 17 | 111286 | Detent Ball, 5/16" diam. | 3 | 12 | £30.00 | - + |
| 18 | 20-41-142 | Detent Spring | 3 | 17 | £30.00 | - + |
| 19 | 29-42-143 | Detent Screw | 3 | 20 | £30.00 | - + |
| 20 | 20-41-144 | Interlock Plate | 1 | 10 | £30.00 | - + |
| 21 | 20-41-145 | Bush - For Interlock | 1 | 2 | £30.00 | - + |
| 22 | 20-41-147 | Bush - For Interlock and Reverse Stop | 1 | 10 | £30.00 | - + |
| 23 | 20-41-146 | Joint - For Bushes | 2 | 15 | £30.00 | - + |
| 24 | 20-41-148 | Spring - For Plunger | 1 | 7 | £30.00 | - + |
| 25 | 20-41-149 | Plunger - Reverse Stop | 1 | 16 | £30.00 | - + |
| 26 | 20-41-150 | Plug - Reverse Stop | 1 | 7 | £30.00 | - + |
| 27 | 114413 | Circlip, Internal, 7/8" | 1 | 7 | £30.00 | - + |
| 28 | 690331 | Socket Setscrew, 1/4" UNC × 5/8" | 8 | 10 | £30.00 | - + |
| 29 | 20-41-125 | Inspection Cover | 2 | 3 | £30.00 | - + |
| 30 | 20-41-222 | Plate - For Cover | 4 | 3 | £30.00 | - + |
| 31 | 20-41-126 | Joint - For Cover | 2 | 18 | £30.00 | - + |
| 32 | 690505 | Socket Setscrew, 1/4" UNC × 1/2" | 8 | 19 | £30.00 | - + |
| 33 | 20-41-151 | Locating Peg | 2 | 13 | £30.00 | - + |
| 34 | 20-41-152 | Change Speed Lever | 1 | 9 | £30.00 | - + |
| - | 20-41-154 | Change Speed Lever | 1 | 1 | £30.00 | - + |
| 35 | 20-41-155 | Knob - Change Speed Lever | 1 | 18 | £30.00 | - + |
| 36 | 20-41-195 | Special Locknut, 5/16" BSF | 1 | 6 | £30.00 | - + |
| 37 | 20-41-156 | Retaining Plate | 1 | 2 | £30.00 | - + |
| 38 | 20-41-157 | Shouldered Screw - For Retaining Plate | 4 | 16 | £30.00 | - + |
| 39 | 20-41-223 | Spring - For Plate | 4 | 15 | £30.00 | - + |
| 40 | 690332 | Socket Setscrew, 1/4" UNC × 3/4" | 8 | 9 | £30.00 | - + |
| 41 | 690333 | Socket Setscrew, 1/4" UNC × 1 1/2" | 4 | 7 | £30.00 | - + |
| - | 20-41-011 | Dipstick Assembly | 1 | 16 | £30.00 | - + |
| 42 | 20-41-159 | Dipstick | 1 | 20 | £30.00 | - + |
| 43 | 20-41-160 | Bush - Dispstick | 1 | 19 | £30.00 | - + |
| 44 | 20-41-161 | Cork - Dipstick | 1 | 17 | £30.00 | - + |
| 45 | 20-41-162 | Knob - Dispstick | 1 | 7 | £30.00 | - + |
| 46 | 20-41-214 | Reverse Fork | 1 | 10 | £30.00 | - + |
| 47 | 20-40-215 | Shaft - For Reverse Fork | 1 | 8 | £30.00 | - + |
| 48 | 690339 | Socket Setscrew, 1/4" UNC × 1 1/4" | 1 | 14 | £30.00 | - + |
| 49 | 690340 | Locknut, 1/4" UNC | 1 | 19 | £30.00 | - + |
| 50 | 20-41-216 | Reverse Operating Lever | 1 | 18 | £30.00 | - + |
| 51 | 20-41-217 | Bolt - For Reverse Lever | 1 | 16 | £30.00 | - + |
| 52 | 690019 | Nut, Nyloc, Thin 5/16" UNF | 1 | 13 | £30.00 | - + |
| 53 | 20-41-100 | Spring Cup - Change Speed Lever | 1 | 16 | £30.00 | - + |
| 54 | 20-41-102 | Spring - Change Speed Lever | 1 | 14 | £30.00 | - + |
Gearbox Central Change Gearbox Top
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 55987 | Rod, Selector, 1st and 2nd | 1 | 7 | £30.00 | - + |
| 2 | 55988 | Rod, Selector, 3rd and 4th | 1 | 13 | £30.00 | - + |
| 3 | 55989 | Rod, Selector, Reverse | 1 | 14 | £30.00 | - + |
| 4 | 55986 | COVER, Top, Gearbox | 1 | 20 | £30.00 | - + |
| 57584 | Joint | 1 | 7 | £30.00 | - + | |
| 5 | 55882 | Fork, 1st and 2nd speed | 1 | 9 | £30.00 | - + |
| 6 | 55883 | Fork, 3rd and 4th speed | 1 | 3 | £30.00 | - + |
| 7 | 55885 | Setscrew, Selector Forks | 2 | 5 | £30.00 | - + |
| 9 | 55884 | Selector, Reverse | 1 | 3 | £30.00 | - + |
| 55886 | Setscrew, Reverse Selector | 1 | 7 | £30.00 | - + | |
| 10 | 113506 | Ball, 3/8in. dia., Cone Stop | 1 | 13 | £30.00 | - + |
| 11 | 57579 | Spring, Cone Stop | 1 | 12 | £30.00 | - + |
| 12 | 55889 | Stop, Cone | 1 | 10 | £30.00 | - + |
| 13 | 55892 | Ball, 5/8in. | 1 | 17 | £30.00 | - + |
| 14 | 55895 | Pin, Interlocking | 1 | 20 | £30.00 | - + |
| 15 | 122223 | Setscrew, 1/4in. Whit. | 6 | 16 | £30.00 | - + |
| 16 | 119480 | Washer, Spring, 1/4in. | 6 | 12 | £30.00 | - + |
| 17 | 56005 | COVER, Inspection | 1 | 4 | £30.00 | - + |
| 18 | 56006 | Gasket, Inspection Cover | 1 | 10 | £30.00 | - + |
| 19 | 56004 | KNOB, Gear Lever | 1 | 10 | £30.00 | - + |
| 20 | 56002 | Screw, Retaining, Gear Lever | 4 | 9 | £30.00 | - + |
| 21 | 56003 | Spring, Gear Lever Retaining Plate | 4 | 6 | £30.00 | - + |
| 22 | 56001 | Plate, Retaining | 1 | 5 | £30.00 | - + |
| 23 | 122226 | Setscrew, 5/16i. Whit. Cover Plate | 2 | 13 | £30.00 | - + |
| 24 | 111902 | Washer, Thackeray | 2 | 9 | £30.00 | - + |
| 25 | 76736 | PLate, Cover, Selector Plungers | 1 | 8 | £30.00 | - + |
| 26 | 76727 | Spring, Selector Plunger | 3 | 10 | £30.00 | - + |
| 55995 | Spring, Selector Plunger | 3 | 16 | £30.00 | - + | |
| 27 | 56007 | Ventilator, (Ball valve type) | 1 | 20 | £30.00 | - + |
| 28 | 55994 | Plunger, Selector | 3 | 12 | £30.00 | - + |
| 29 | 76737 | Joint, Plunger Plate | 1 | 6 | £30.00 | - + |
| 30 | 55975 | Gasket, Inspection Cover | 1 | 12 | £30.00 | - + |
| 31 | 55974 | COVER, Inspection | 1 | 12 | £30.00 | - + |
| 32 | 122223 | Setscrew, 1/4in. Whit. | 8 | 20 | £30.00 | - + |
| 33 | 119480 | Washer, Spring, 1/4in. | 8 | 15 | £30.00 | - + |
| 34 | 55896 | Plug, Welch | 3 | 1 | £30.00 | - + |
| 35 | 55897 | Plug, 1/2in. BSP | 1 | 10 | £30.00 | - + |
| 36 | 55898 | Washer, Fibre | 1 | 11 | £30.00 | - + |
| 37 | 119441 | Nut, Lock, Knob | 1 | 2 | £30.00 | - + |
| 73447 | Gaiter | 1 | 8 | £30.00 | - + | |
| 38 | 55997 | LEVER, Gearchange | 1 | 13 | £30.00 | - + |
| 39 | 55974 | COVER, Inspection | 1 | 8 | £30.00 | - + |
| 40 | 55975 | Gasket, Inspection Cover | 1 | 10 | £30.00 | - + |
| 41 | 55979 | DIPSTICK ASSEMBLY | 1 | 9 | £30.00 | - + |
| 42 | 55993 | Tube, Cone Stop | 1 | 4 | £30.00 | - + |
| 43 | 55991 | Stop, 1st speed | 1 | 13 | £30.00 | - + |
| 44 | 55879 | Stop, 2nd speed | 1 | 3 | £30.00 | - + |
| 45 | 55880 | Stop, 3rd speed | 1 | 12 | £30.00 | - + |
| 46 | 55881 | Stop, Reverse speed | 1 | 7 | £30.00 | - + |
| 73447 | Seal, rubber gearbox cover | 1 | 15 | £30.00 | - + | |
| 73511 | Clip, cover, seal | 1 | 14 | £30.00 | - + |
Gearbox Geartrain
Gearbox Remote Change Gearbox Top
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 55897 | Plug, 1/2in. BSP | 1 | 19 | £30.00 | - + |
| 2 | 55898 | Washer, Fibre | 1 | 4 | £30.00 | - + |
| 5 | 122223 | Setscrew, 1/4in.Whit. | 4 | 19 | £30.00 | - + |
| 6 | 119480 | Washer, Spring, 1/4in. | 4 | 17 | £30.00 | - + |
| 7 | 55974 | COVER, Inspection | 1 | 17 | £30.00 | - + |
| 8 | 56009 | Nut, Lock | 1 | 17 | £30.00 | - + |
| 9 | 56008 | Screw, Adjusting | 3 | 20 | £30.00 | - + |
| 10 | 55894 | Spring, Plunger | 3 | 4 | £30.00 | - + |
| 11 | 55893 | Plunger | 3 | 3 | £30.00 | - + |
| 12 | 55975 | Gasket, Inspection Cover | 1 | 12 | £30.00 | - + |
| 14 | 119471 | Washer, Plain, 5/16in. | 1 | 4 | £30.00 | - + |
| 15 | 55977 | Spring, Retaining, Oil Cap | 1 | 3 | £30.00 | - + |
| 16 | 55978 | Washer, Support, Retaining Spring | 1 | 8 | £30.00 | - + |
| 17 | 55976 | Cap, Oil Filler | 1 | 4 | £30.00 | - + |
| 18 | 119480 | Washer, Spring, 1/4in. | 1 | 6 | £30.00 | - + |
| 19 | 55887 | Screw, Locating | 1 | 19 | £30.00 | - + |
| 20 | 55896 | Plug, Welch | 3 | 9 | £30.00 | - + |
| 21 | 55874 | COVER, Top Gearbox | 1 | 8 | £30.00 | - + |
| 57584 | Joint, top cover | 1 | 18 | £30.00 | - + | |
| 22 | 55891 | Ball, 3/8in.dia. Cone Stop | 1 | 16 | £30.00 | - + |
| 23 | 57579 | Spring, Cone Stop | 1 | 9 | £30.00 | - + |
| 24 | 55889 | Cone Stop | 1 | 18 | £30.00 | - + |
| 25 | 55877 | Rod, Selector, Reverse | 1 | 14 | £30.00 | - + |
| 26 | 55884 | Fork, Selector, Reverse | 1 | 2 | £30.00 | - + |
| 27 | 55886 | Setscrew, Reverse Fork | 1 | 8 | £30.00 | - + |
| 28 | 55876 | Rod, Selector, 3rd and 4th | 1 | 12 | £30.00 | - + |
| 29 | 55878 | Stop, 1st speed | 1 | 13 | £30.00 | - + |
| 30 | 55888 | Tube, Cone Stop | 1 | 1 | £30.00 | - + |
| 31 | 55875 | Rod, Selector, 1st and 2nd | 1 | 16 | £30.00 | - + |
| 32 | 55882 | Fork, 1st and 2nd speed | 1 | 8 | £30.00 | - + |
| 33 | 55885 | Setscrew, Selector Forks | 2 | 9 | £30.00 | - + |
| 34 | 55883 | Fork, 3rd and 4th Speed | 1 | 10 | £30.00 | - + |
| 35 | 55880 | Stop, 3rd speed | 1 | 20 | £30.00 | - + |
| 36 | 55895 | Pin, Interlocking | 1 | 20 | £30.00 | - + |
| 37 | 55881 | Stop, Reverse | 1 | 12 | £30.00 | - + |
| 38 | 55879 | Stop, 2nd Speed | 1 | 13 | £30.00 | - + |
| 39 | 55892 | Ball, Locking, 5/8in. Diameter | 2 | 12 | £30.00 | - + |
| 40 | 55979 | DIPSTICK ASSEMBLY | 1 | 13 | £30.00 | - + |
Gearbox, Geartrain
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 201-41-163 | Primary Shaft | 1 | 9 | £30.00 | - + |
| 2 | 690345 | Ball Bearing | 1 | 16 | £30.00 | - + |
| 3 | 20-41-165 | Tabwasher | 1 | 4 | £30.00 | - + |
| 4 | 20-41-166 | Locknut | 1 | 8 | £30.00 | - + |
| 5 | 20-41-168 | Retaining Ring | 1 | 15 | £30.00 | - + |
| 6 | 20-41-224 | Clutch - 3rd and 4th Speed | 1 | 4 | £30.00 | - + |
| 7 | 20-41-164 | Bearing Housing | 1 | 12 | £30.00 | - + |
| 8 | 114426 | Oil Seal | 1 | 15 | £30.00 | - + |
| 9 | 20-41-169 | Cover - Primary Shaft | 1 | 12 | £30.00 | - + |
| 10 | 690334 | Socket Capscrew, 5/16" UNC × 5/8" | 6 | 20 | £30.00 | - + |
| 11 | 20-41-170 | Mainshaft | 1 | 14 | £30.00 | - + |
| - | 20-41-240 | Mainshaft | 1 | 17 | £30.00 | - + |
| - | 24-41-170 | Mainshaft | 1 | 20 | £30.00 | - + |
| - | 24-41-235 | Tab Washer | 1 | 16 | £30.00 | - + |
| - | 24-41-236 | Nut | 1 | 17 | £30.00 | - + |
| - | 24-41-031 | Adaptor Assembly | 1 | 4 | £30.00 | - + |
| - | 122487 | Filler Plug | 1 | 16 | £30.00 | - + |
| - | 24-41-239 | Oil Seal | 2 | 7 | £30.00 | - + |
| - | UCB105/30R | Bolt | 1 | 19 | £30.00 | - + |
| - | UCB105/9R | Bolt | 6 | 7 | £30.00 | - + |
| - | UCB105/7R | Setscrew | 2 | 17 | £30.00 | - + |
| - | 111902 | Washer | 9 | 17 | £30.00 | - + |
| - | 24-41-248 | Overdrive (.820 ratio) | 1 | 12 | £30.00 | - + |
| - | 24-41-701 | Mangnetic Ring | 1 | 7 | £30.00 | - + |
| - | 24-41-702 | Fibre Washer | 1 | 20 | £30.00 | - + |
| - | 125495 | Circlip | 1 | 12 | £30.00 | - + |
| - | 20-41-231 | Locking Screw | 1 | 9 | £30.00 | - + |
| - | 20-41-232 | Locking Washer | 1 | 18 | £30.00 | - + |
| 12 | 20-41-171 | Gear - 3rd Speed | 1 | 11 | £30.00 | - + |
| 13 | 20-41-224 | Clutch - 3rd and 4th Speed | 1 | 16 | £30.00 | - + |
| 14 | 20-41-168 | Retaining Ring | 1 | 1 | £30.00 | - + |
| 15 | 690335 | Needle Roller, 3 mm. | 286 | 16 | £30.00 | - + |
| 16 | 20-41-172 | Distance Piece, 3rd and 4th Speed | 2 | 14 | £30.00 | - + |
| 17 | 20-41-225 | Synchro Cone - 1st, 3rd and 4th Speed | 3 | 19 | £30.00 | - + |
| - | 20-41-225 | Synchro Cone - 3rd and 4th Speed | 2 | 14 | £30.00 | - + |
| - | 20-41-234 | Synchro Cone - 1st Speed | 1 | 9 | £30.00 | - + |
| 18 | 20-41-174 | Key - For Hub | 1 | 6 | £30.00 | - + |
| 19 | 20-41-175 | Hub - 3rd and 4th Speed Clutch | 1 | 15 | £30.00 | - + |
| 20 | 20-41-176 | Synchro Spring - 1st and 2nd Speed - Short | 3 | 7 | £30.00 | - + |
| - | 20-41-230 | Synchro Spring - 3rd and 4th Speed - Long | 3 | 16 | £30.00 | - + |
| 82090e133f48 | Note: Prior to DB4/759 all synchro cones must be serviced as assemblies. | 12 | £30.00 | - + | ||
| - | 20-41-223 | Plunger - For Synchro Spring | 6 | 16 | £30.00 | - + |
| 21 | 690388 | Ball, 9/32" diam. | 6 | 9 | £30.00 | - + |
| 22 | 20-41-244 | Saddle | 6 | 16 | £30.00 | - + |
| 23 | 20-41-178 | Sliding Clutch - 3rd and 4th Speed | 1 | 20 | £30.00 | - + |
| 24 | 20-41-226 | Gear - 2nd Speed | 1 | 9 | £30.00 | - + |
| 25 | 20-41-183 | Distance Piece - 1st and 2nd Speed | 2 | 14 | £30.00 | - + |
| 26 | 20-41-229 | Synchro Cone - 2nd Speed | 1 | 3 | £30.00 | - + |
| 27 | 20-41-184 | Key - For Hub | 2 | 13 | £30.00 | - + |
| 28 | 20-41-185 | Hub - 1st and 2nd Speed Clutch | 1 | 11 | £30.00 | - + |
| 29 | 20-41-186 | Sliding Clutch Reverse Gear - 1st and 2nd Speed | 1 | 2 | £30.00 | - + |
| 30 | 20-41-227 | Gear - 1st Speed | 1 | 8 | £30.00 | - + |
| - | 23-41-227 | Gear 1st Speed | 1 | 17 | £30.00 | - + |
| 31 | 20-41-188 | Bearning Bush - 1st Speed Gear | 1 | 18 | £30.00 | - + |
| - | 23-41-188 | Bearning Bush - 1st Speed Gear | 1 | 7 | £30.00 | - + |
| 32 | 20-41-180 | Spacing Bush | 1 | 19 | £30.00 | - + |
| 33 | 20-41-196 | Shim - for Spacing Bush | 1 set | 20 | £30.00 | - + |
| 34 | 20-41-181 | Roller Bearing | 1 | 6 | £30.00 | - + |
| 35 | 34454 | Circlip, External, 7/8" | 1 | 14 | £30.00 | - + |
| 36 | 20-41-189 | Bearing Housing | 1 | 12 | £30.00 | - + |
| 37 | 20-41-228 | Shim - for Mainshaft Bearing | 1 set | 1 | £30.00 | - + |
| 38 | 690345 | Ball Bearing | 1 | 19 | £30.00 | - + |
| 39 | 20-41-190 | Retaining Washer - Bearing | 1 | 10 | £30.00 | - + |
| - | 23-41-190 | Retaining Washer - Bearing | 1 | 10 | £30.00 | - + |
| 40 | 20-41-191 | Speedometer Gear Wheel | 1 | 13 | £30.00 | - + |
| - | 42-41-191 | Speedometer Gear Wheel | 1 | 17 | £30.00 | - + |
| 41 | 20-41-194 | Coupling Flange | 1 | 18 | £30.00 | - + |
| 42 | 20-41-192 | Retaining Washer - Flange | 1 | 8 | £30.00 | - + |
| 43 | 20-41-193 | Nut, Slotted, 7/8" UNF | 1 | 3 | £30.00 | - + |
| 44 | 119533 | Split Pin, 1/8" diam. × 1 1/2" | 1 | 8 | £30.00 | - + |
| 45 | 20-41-199 | Layshaft | 1 | 15 | £30.00 | - + |
| 46 | 20-41-200 | Cluster, Layshaft | 1 | 9 | £30.00 | - + |
| 47 | 690336 | Circlip, External, 1 3/4" | 1 | 2 | £30.00 | - + |
| 48 | 20-41-201 | Spindle, Layshaft | 1 | 11 | £30.00 | - + |
| 49 | 20-41-204 | Roller Cage | 2 | 20 | £30.00 | - + |
| - | 48-41-201 | Spindle, Layshaft | 1 | 15 | £30.00 | - + |
| - | 48-41-204 | Roller Cage | 2 | 6 | £30.00 | - + |
| 50 | 20-41-203 | Thrust Washer | 2 | 4 | £30.00 | - + |
| 51 | 690338 | Needle Thrust Bearing | 2 | 8 | £30.00 | - + |
| 52 | 20-41-205 | Front Support Bush | 1 | 15 | £30.00 | - + |
| 53 | 20-41-206 | Shim - for Front Support Bush | 1 set | 5 | £30.00 | - + |
| 54 | 690337 | Socket Setscrew, 5/16" UNF × 1/2" | 1 | 4 | £30.00 | - + |
| 55 | 20-41-202 | Rear Support Bush | 1 | 20 | £30.00 | - + |
| 56 | 20-41-208 | Reverse Shaft | 1 | 13 | £30.00 | - + |
| - | 23-41-208 | Reverse Shaft | 1 | 12 | £30.00 | - + |
| 57 | 20-41-209 | Sliding Gear - Reverse | 1 | 14 | £30.00 | - + |
| 58 | 20-41-207 | Front Bearing Bush | 1 | 14 | £30.00 | - + |
| 59 | 20-41-210 | Thrust Washer | 1 | 5 | £30.00 | - + |
| 60 | 20-41-211 | Rear Bearing Bush | 1 | 13 | £30.00 | - + |
| 61 | 20-41-212 | Shim - for Rear Bearing Bush | 1 set | 9 | £30.00 | - + |
| 62 | 20-41-213 | Distance Piece | 1 | 2 | £30.00 | - + |
| 63 | 20-41-218 | Rear Cover | 1 | 20 | £30.00 | - + |
| - | 23-41-213 | Distance Piece | 1 | 15 | £30.00 | - + |
| - | 23-41-012 | Rear Cover | 1 | 15 | £30.00 | - + |
| 64 | 20-41-219 | Bush | 1 | 19 | £30.00 | - + |
| 65 | 20-41-220 | Speedometer Pinion | 1 | 3 | £30.00 | - + |
| - | 42-41-220 | Speedometer Pinion | 1 | 3 | £30.00 | - + |
| 66 | 20-41-221 | Adaptor - Speedometer Pinion | 1 | 4 | £30.00 | - + |
| 67 | 123163 | Oil Seal - for Pinion | 1 | 6 | £30.00 | - + |
| 68 | 115757 | Oil Seal - for Coupling Flange | 1 | 4 | £30.00 | - + |
| 69 | 690341 | Socket Setscrew, 5/16" UNC × 7/8" | 6 | 3 | £30.00 | - + |
| 70 | 690342 | Socket Setscrew, 5/16" UNC × 1 1/2" | 1 | 10 | £30.00 | - + |
| 71 | 690343 | Socket Setscrew, 5/16" UNC × 2" | 1 | 6 | £30.00 | - + |
| 72 | 690344 | Socket Setscrew, 5/16" UNC × 1" | 1 | 19 | £30.00 | - + |
Handbrake
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-30-001 | Hand Brake Lever Assembly - R.H.D. | 1 | 9 | £30.00 | - + |
| - | 20-30-002 | Hand Brake Lever Assembly - L.H.D. | 1 | 15 | £30.00 | - + |
| 2 | 690144 | Circlip, Internal | 1 | 11 | £30.00 | - + |
| 3 | 20-30-120 | Lock Plunger | 1 | 12 | £30.00 | - + |
| 4 | 20-30-123 | Link Pin | 1 | 3 | £30.00 | - + |
| 5 | 20-30-003 | Pawl Link Assembly | 1 | 17 | £30.00 | - + |
| 6 | 690423 | Spring - Lock Plunger | 1 | 19 | £30.00 | - + |
| 7 | 20-30-124 | Pawl Pivot Bolt | 1 | 20 | £30.00 | - + |
| 8 | 110822 | Split Pin, 1/32" diam. × 3/8" | 1 | 19 | £30.00 | - + |
| 9 | 20-30-122 | Pivot Pin - Pawl Link | 1 | 9 | £30.00 | - + |
| 10 | 20-30-004 | Pawl Assembly - R.H.D. | 1 | 15 | £30.00 | - + |
| - | 20-30-005 | Pawl Assembly - L.H.D. | 1 | 8 | £30.00 | - + |
| 11 | 122442 | Plain Washer, 3/16", Chromed | 1 | 16 | £30.00 | - + |
| 12 | 112941 | Locknut, 2 BA | 2 | 8 | £30.00 | - + |
| 13 | 690504 | Tension Pin, 1/4" diam. × 1 1/2" | 1 | 12 | £30.00 | - + |
| 14 | 690143 | Screw, 5/16" UNF × 3/4", C'sk. Hd. | 2 | 17 | £30.00 | - + |
| 15 | 20-30-153 | Ratchet - R.H.D. | 1 | 18 | £30.00 | - + |
| - | 20-30-154 | Ratchet - L.H.D. | 1 | 1 | £30.00 | - + |
| 16 | 690384 | Bolt, 2 BA × 5/8" | 1 | 6 | £30.00 | - + |
| 17 | 112941 | Locknut, 2 BA | 1 | 6 | £30.00 | - + |
| 18 | 20-30-011 | Stop Bracket Assembly - R.H.D. | 1 | 15 | £30.00 | - + |
| - | 20-30-012 | Stop Bracket Assembly - L.H.D. | 1 | 2 | £30.00 | - + |
| 19 | 119481 | Spring Washer, 5/16" | 2 | 13 | £30.00 | - + |
| 20 | 125557 | Plain Nut, 5/16" UNF | 2 | 5 | £30.00 | - + |
| 21 | 20-30-013 | Mounting Tube Assembly - R.H.D. | 1 | 13 | £30.00 | - + |
| - | 20-30-014 | Mounting Tube Assembly - L.H.D. | 1 | 12 | £30.00 | - + |
| 22 | 20-30-126 | Cross Tube | 1 | 12 | £30.00 | - + |
| 24 | 119480 | Spring Washer, 1/4" | 8 | 10 | £30.00 | - + |
| 25 | 690145 | Bush | 2 | 18 | £30.00 | - + |
| 26 | 111732 | Screw, 2 BA × 1/2", C'sk. Hd. | 3 | 3 | £30.00 | - + |
| 27 | 20-30-155 | Tunnell Socket | 1 | 5 | £30.00 | - + |
| 28 | 20-30-127 | Sealing Grommet | 1 | 18 | £30.00 | - + |
| 29 | 122442 | Plain Washer, 3/16", Chromed | 3 | 4 | £30.00 | - + |
| 30 | 122315 | Nut, Nyloc, 2 BA | 3 | 15 | £30.00 | - + |
| 31 | 20-30-128 | Lever - Crosstube | 1 | 3 | £30.00 | - + |
| 32 | 690504 | Tension Pin, 1/4" diam. × 1 1/2" | 1 | 13 | £30.00 | - + |
| 33 | 20-30-139 | Fork End | 2 | 12 | £30.00 | - + |
| 34 | 20-30-129 | Pivot Pin, Long | 2 | 10 | £30.00 | - + |
| 35 | 20-30-119 | Cleat - Return Spring | 1 | 17 | £30.00 | - + |
| 36 | 110823 | Split Pin, 3/64 " diam. × 1/2" | 2 | 7 | £30.00 | - + |
| 37 | 125583 | Plain Nut, 1/4" UNF | 2 | 8 | £30.00 | - + |
| 38 | 20-30-140 | Threaded Rod | 1 | 1 | £30.00 | - + |
| 39 | 20-30-121 | Compensating Arm | 1 | 8 | £30.00 | - + |
| 40 | 20-30-130 | Pivot Pin, Short | 2 | 9 | £30.00 | - + |
| 41 | 119470 | Plain Washer, 1/4" | 3 | 8 | £30.00 | - + |
| 42 | 110823 | Split Pin, 3/64" diam. × 1/2" | 2 | 5 | £30.00 | - + |
| 43 | 20-30-161 | Return Spring | 1 | 12 | £30.00 | - + |
| 44 | 20-30-163 | Anchor Bracket | 1 | 17 | £30.00 | - + |
| - | 690076 | Screw, 4 BA × 3/8", Ch. Hd. | 2 | 20 | £30.00 | - + |
| - | 110856 | Spring Washer, 4 BA | 2 | 1 | £30.00 | - + |
| 45 | 122375 | Bung | 1 | 16 | £30.00 | - + |
| 46 | 20-30-010 | Cable, Hand Brake, Assembly | 2 | 5 | £30.00 | - + |
| 47 | 20-30-152 | Pivot Pin, 5/16" - Caliper Lever Arm | 2 | 10 | £30.00 | - + |
| 48 | 119471 | Plain Washer, 5/16" | 2 | 18 | £30.00 | - + |
| 49 | 110823 | Split Pin, 3/64" diam. × 1/2" | 2 | 10 | £30.00 | - + |
| 50 | 20-30-156 | Cable Clip, Dual | 1 | 5 | £30.00 | - + |
| 51 | 114666 | Bolt, 2 BA × 1/4" | 1 | 18 | £30.00 | - + |
| 52 | 122442 | Plain Washer, 3/16" | 1 | 13 | £30.00 | - + |
| 53 | 122315 | Nut, Nyloc, 2 BA | 1 | 9 | £30.00 | - + |
| 54 | 20-37-191 | Cable Clip, Single | 2 | 5 | £30.00 | - + |
| 20-30-749 | Grease Nipple, Special | 2 | 9 | £30.00 | - + |
Heater
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 55263 | HEATER, Recirculating Type | 1 | 16 | £30.00 | - + |
| 2 | 55266 | Cover, Heater | 1 | 18 | £30.00 | - + |
| 73381 | Cover, Heater | 1 | 9 | £30.00 | - + | |
| 3 | 55264 | Pan, Heater | 1 | 17 | £30.00 | - + |
| 4 | 55837 | VALVE, Water | 1 | 14 | £30.00 | - + |
| 5 | 57723 | Adaptor, Water Valve | 1 | 11 | £30.00 | - + |
| 6 | 58867 | Washer, Fibre, Water Valve | 1 | 13 | £30.00 | - + |
| 7 | 110883 | Clip, Water Hose | 1 | 18 | £30.00 | - + |
| 8 | 75400 | Elbow, 1/2in. Bore, Water | 1 | 14 | £30.00 | - + |
| 9 | 110883 | Clip, Water Hose | 1 | 9 | £30.00 | - + |
| 10 | 55192 | Pipe, Return, Water | 1 | 9 | £30.00 | - + |
| 57736 | Pipe, Return, Water | 1 | 12 | £30.00 | - + | |
| 11 | 57737 | Clip, Water Return Pipe | 1 | 3 | £30.00 | - + |
| 12 | 57735 | Pipe, Heater Inlet | 1 | 13 | £30.00 | - + |
| 13 | 110883 | Clip, Water Hose | 4 | 12 | £30.00 | - + |
| 14 | 57683 | Hose, Connection, Inlet and Outlet | 1 | 8 | £30.00 | - + |
| 15 | 110883 | Clip, Water Hose | 2 | 11 | £30.00 | - + |
| 16 | 55271 | Duct, Heater | 1 | 11 | £30.00 | - + |
| 17 | 110883 | Clip, Water Hose | 1 | 10 | £30.00 | - + |
| 18 | 74967 | Pipe, Heater Pan, Water Drain | 1 | 19 | £30.00 | - + |
| 19 | 51446 | Clip, Water Drain Pipe | 1 | 15 | £30.00 | - + |
| 20 | 73384 | Bracket, Steady | 1 | 15 | £30.00 | - + |
| 21 | 73390 | BOOSTER UNIT | 1 | 17 | £30.00 | - + |
| 22 | 50278 | Clip, Jubilee, No. 1X | 2 | 10 | £30.00 | - + |
| 23 | 55270 | Hose, Air, Demister Conn. | 1 | 13 | £30.00 | - + |
| 74577 | Hose, Booster, to Demister | 1 | 8 | £30.00 | - + | |
| 24 | 73387 | Strip, Sealing, Booster Duct | 1 | 13 | £30.00 | - + |
| 25 | 73382 | Duct, Booster | 1 | 7 | £30.00 | - + |
| 26 | 74241 | Ring, Support, Booster | 1 | 1 | £30.00 | - + |
| 27 | 122351 | 36in. 1/2in. X 1/4in. Sponge Rubber | As req'd | 3 | £30.00 | - + |
| 28 | 55268 | Ring, Seal, Heater | 1 | 5 | £30.00 | - + |
| 73383 | Ring, Seal, Heater | 1 | 3 | £30.00 | - + | |
| 29 | 55269 | Ring, Seal, External | 1 | 6 | £30.00 | - + |
| 30 | 51730 | Hose, Water, 1/2in. Bore | 1 | 10 | £30.00 | - + |
| 55195 | Elbow, Assembly, Heater Water Valve | 1 | 10 | £30.00 | - + | |
| 55196 | Flange, Elbow Assembly | 1 | 12 | £30.00 | - + | |
| 50855 | Grommet, Control Cable | 1 | 6 | £30.00 | - + | |
| 55198 | Ring, Sealing, Water Valve | 1 | 11 | £30.00 | - + |
Heater and Controls
Instruments and Controls
Oil Pump
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-04-122 | Sump | 1 | 11 | £30.00 | - + |
| - | 21-04-122 | Sump | 1 | 17 | £30.00 | - + |
| 2 | 20-04-121 | Joint - Sump | 1 | 6 | £30.00 | - + |
| 3 | 121841 | Locking Wire, 16 SWG | 6 ft. | 6 | £30.00 | - + |
| 4 | 690314 | Setscrew, 5/16" UNC × 1 1/8" - Sump to Cylinder Block | 26 | 16 | £30.00 | - + |
| 5 | 111902 | Thackeray Spring Washer 5/16" | 26 | 3 | £30.00 | - + |
| 6 | 20-04-111 | Joint - Oill Pump | 1 | 2 | £30.00 | - + |
| 7 | 20-04-001 | Oil Pump Complete | 1 | 11 | £30.00 | - + |
| - | 48-04-001 | Oil Pump Complete | 1 | 13 | £30.00 | - + |
| - | 690481 | Adaptor - Thermo bulb | 1 | 2 | £30.00 | - + |
| - | 690610 | Adaptor - Thermo bulb | 1 | 4 | £30.00 | - + |
| - | 690397 | Plug - 3/8" Bsp | 1 | 1 | £30.00 | - + |
| - | 690610 | Adaptor - Thermo gauge | 1 | 20 | £30.00 | - + |
| 8 | 690464 | Stud, 5/16" UNC/UNF × 3.775" | 4 | 1 | £30.00 | - + |
| 9 | 125542 | Special Washer | 1 | 10 | £30.00 | - + |
| 10 | 125443 | Slotted Nut, 1/2" UNF | 1 | 1 | £30.00 | - + |
| 11 | 119528 | Split Pin, 3/32" diam. × 1" | 1 | 15 | £30.00 | - + |
| 12 | 119608 | Woodruff Key. No. 9 | 1 | 16 | £30.00 | - + |
| 13 | 123113 | Nut, Nyloc, 3/8" UNF | 4 | 19 | £30.00 | - + |
| 14 | 119472 | Plain Washer, 3/8" | 4 | 19 | £30.00 | - + |
| 15 | 20-04-003 | Oil Strainer Assembly | 1 | 14 | £30.00 | - + |
| - | 21-04-003 | Oil Strainer Assembly | 1 | 15 | £30.00 | - + |
| - | 23-04-003 | Oil Strainer Assembly | 1 | 2 | £30.00 | - + |
| 16 | 119502 | Fibre Washer - for 1/2" BSP | 1 | 12 | £30.00 | - + |
| 17 | 690165 | Oil Drain Plug, 1/2" BSP, Magnetic | 1 | 9 | £30.00 | - + |
| 18 | 125522 | Setscrew, 5/16" UNC × 1" | 5 | 8 | £30.00 | - + |
| 19 | 119481 | Spring Washer, 5/16" | 7 | 1 | £30.00 | - + |
| 20 | 125524 | Sealing Ring | 2 | 3 | £30.00 | - + |
| 21 | 20-04-113 | Baffle Plate - Sump | 1 | 17 | £30.00 | - + |
| - | 23-04-113 | Baffle Plate - Sump | 1 | 4 | £30.00 | - + |
| 22 | 20-04-005 | Suction Pipe Assembly | 1 | 8 | £30.00 | - + |
| 23 | 125519 | Setscrew, 5/16" UNF × 5/8" | 2 | 1 | £30.00 | - + |
| 24 | 119470 | Plain Washer, 1/4" | 7 | 2 | £30.00 | - + |
| 25 | 119480 | Spring Washer, 1/4" | 7 | 10 | £30.00 | - + |
| 26 | 690022 | Setscrew, 1/4" UNC × 1 1/8" | 7 | 18 | £30.00 | - + |
| 27 | 119471 | Plain Washer, 5/16" | 3 | 15 | £30.00 | - + |
Pedals and Pedal Gear
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-29-113 | Clutch Pedal Lever | 1 | 11 | £30.00 | - + |
| 2 | 20-29-111 | Brake Pedal Lever | 1 | 6 | £30.00 | - + |
| - | 20-29-156 | Pedal Return Spring | 2 | 19 | £30.00 | - + |
| 3 | 20-29-114 | Pedal Pad | 2 | 4 | £30.00 | - + |
| 4 | 20-29-141 | Rubber Pad | 2 | 14 | £30.00 | - + |
| 5 | 123131 | Bolt, 5/16" UNF × 1" | 2 | 20 | £30.00 | - + |
| 6 | 119471 | Plain Washer, 5/16" | 2 | 13 | £30.00 | - + |
| 7 | 123115 | Nut, Nyloc, 5/16" UNF | 2 | 19 | £30.00 | - + |
| 8 | 690041 | Bush, Pedal Levers | 4 | 3 | £30.00 | - + |
| 9 | 20-29-117 | Pivot Pin, Pedals | 1 | 19 | £30.00 | - + |
| - | 21-29-117 | Pivot Pin, Pedals | 1 | 7 | £30.00 | - + |
| 10 | 111290 | Circlip, External, 3/4" | 2 | 17 | £30.00 | - + |
| 11 | 690552 | Socket Setscrew, 2 BA × 1/2" | 1 | 5 | £30.00 | - + |
| 12 | 20-29-116 | Support Bracket - Pedals | 1 | 5 | £30.00 | - + |
| 13 | 20-29-144 | Mounting Bracket - Master Cylinders | 1 | 7 | £30.00 | - + |
| 14 | 690347 | Bolt, 5/16" UNF × 6 1/2" | 1 | 3 | £30.00 | - + |
| 15 | 690062 | Bolt, 5/16" UNF × 3 1/2" | 4 | 11 | £30.00 | - + |
| - | 690062 | Bolt, 5/16" UNF × 3 1/2" | 3 | 10 | £30.00 | - + |
| - | 690458 | Stud, 5/16" UNC/UNF × 6.55" | 2 | 3 | £30.00 | - + |
| 16 | 119471 | Plain Washer, 5/16" | 5 | 15 | £30.00 | - + |
| 17 | 123115 | Nut, Nyloc, 5/16" UNF | 5 | 17 | £30.00 | - + |
| 18 | 20-29-145 | Push Rod Assembly | 2 | 11 | £30.00 | - + |
| - | 125557 | Locknut, 5/16" UNF | 2 | 12 | £30.00 | - + |
| 19 | 122340 | Headed Pin | 2 | 3 | £30.00 | - + |
| 20 | 20-29-148 | Spring Anchor | 2 | 9 | £30.00 | - + |
| 21 | 119527 | Split Pin, 3/32" diam. × 3/4" | 2 | 16 | £30.00 | - + |
| 22 | 20-29-004 | Cover Plate Assembly | 2 | 12 | £30.00 | - + |
| 23 | 20-29-120 | Gaiter | 2 | 17 | £30.00 | - + |
| 24 | 20-29-119 | Stop Plate | 2 | 19 | £30.00 | - + |
| 25 | 119471 | Plain Washer, 5/16" | 4 | 10 | £30.00 | - + |
| 26 | 123115 | Nut, Nyloc, 5/16" UNF | 4 | 12 | £30.00 | - + |
| 27 | 21-29-149 | Shield Assembly - Pedal Gear - R.H.D. | 1 | 9 | £30.00 | - + |
| 28 | 21-29-150 | Shield Assembly - Pedal Gear - L.H.D. | 1 | 6 | £30.00 | - + |
| - | 122013 | Screw, P. K. No. 6 Hex. Hd. | 11 | 7 | £30.00 | - + |
| 29 | 20-29-167 | Adjuster - Return Spring | 2 | 1 | £30.00 | - + |
| 30 | 119470 | Plain Washer, 1/4" | 2 | 13 | £30.00 | - + |
| 31 | 690402 | Locknut, 1/4" UNF | 4 | 9 | £30.00 | - + |
| 32 | 20-29-156 | Spring Pedal Return | 2 | 6 | £30.00 | - + |
| 33 | 20-29-182 | Access Panel - Master Cylinders | 2 | 14 | £30.00 | - + |
| 34 | 20-29-160 | Footwell Assembly | 1 | 19 | £30.00 | - + |
| 35 | 20-29-157 | Blanking Cover Assembly | 1 | 1 | £30.00 | - + |
| 36 | 119650 | Rivet, 1/2" | 108 | 14 | £30.00 | - + |
| 37 | 20-29-158 | Footwell | 1 | 18 | £30.00 | - + |
| 38 | 20-29-159 | Blanking Cover Assembly | 1 | 8 | £30.00 | - + |
| 39 | 123132 | Bolt, 5/16" UNF × 1 3/8" - for Master Cylinder | 4 | 5 | £30.00 | - + |
| 40 | 119471 | Plain Washer, 5/16" | 4 | 10 | £30.00 | - + |
| 41 | 123115 | Nut, Nyloc, 5/16" UNF | 4 | 11 | £30.00 | - + |
| 42 | 20-29-006 | Accelerator Pedal Assembly | 1 | 7 | £30.00 | - + |
| 43 | 20-29-005 | Bearing Bracket Assembly | 1 | 7 | £30.00 | - + |
| 44 | 123127 | Bolt, 1/4" UNF × 3/4" | 2 | 7 | £30.00 | - + |
| 45 | 690046 | Nut, Nyloc, 1/4" UNF - R.H.D. | 2 | 2 | £30.00 | - + |
| - | 125566 | Nut, Nyloc, 1/4" UNF - L.H.D. | 2 | 5 | £30.00 | - + |
| - | 119480 | Spring Washer, 1/4 - L.H.D. | 2 | 10 | £30.00 | - + |
| 46 | 20-29-132 | Bush | 2 | 3 | £30.00 | - + |
| 47 | 20-29-131 | Bearing Spindle | 1 | 19 | £30.00 | - + |
| 48 | 690044 | Pivot Bolt, 1/4" UNF × 2" | 1 | 6 | £30.00 | - + |
| 49 | 690046 | Nut, Nyloc, 1/4" UNF | 1 | 3 | £30.00 | - + |
| 50 | 110807 | Screw, 2 BA × 1", Hex. HD. | 1 | 20 | £30.00 | - + |
| 51 | 112941 | Locknut, 2 BA | 1 | 19 | £30.00 | - + |
| 52 | 119496 | Plain Washer, 3/16" | 1 | 14 | £30.00 | - + |
| 53 | 20-29-142 | Stop - Accelerator Pedal | 1 | 17 | £30.00 | - + |
| 54 | 123115 | Nut, Nyloc, 5/16" UNF | 1 | 15 | £30.00 | - + |
| 55 | 20-29-007 | Accelerator Pedal Lever Assembly - R.H.D. | 1 | 11 | £30.00 | - + |
| 56 | 20-29-134 | Roller | 1 | 16 | £30.00 | - + |
| 57 | 20-29-133 | Distance Sleeve | 1 | 7 | £30.00 | - + |
| 58 | 112135 | Screw, 2 BA × 1 3/8" Ch. Hd. | 1 | 2 | £30.00 | - + |
| 59 | 122315 | Nut, Nyloc, 2 BA | 1 | 4 | £30.00 | - + |
| 60 | 20-29-136 | Pedal Lever Support Tube Assembly | 1 | 6 | £30.00 | - + |
| 61 | 690049 | Bush | 2 | 14 | £30.00 | - + |
| 62 | 125566 | Nut, Avlok, 1/4" UNF | 4 | 11 | £30.00 | - + |
| 63 | 125581 | Bolt, 1/4" UNF × 1 1/8" | 4 | 7 | £30.00 | - + |
| 64 | 119480 | Spring Washer, 1/4" | 4 | 3 | £30.00 | - + |
| 65 | 690150 | Special Washer, 1/4" | 4 | 1 | £30.00 | - + |
| 66 | 20-29-139 | Spring, Pedal Lever, RH | 1 | 15 | £30.00 | - + |
| 67 | 690149 | Grommet | 1 | 5 | £30.00 | - + |
| 68 | 690306 | Rubber Plug | 1 | 1 | £30.00 | - + |
| 69 | 20-29-008 | Accelerator Pedal Lever Assembly | 1 | 19 | £30.00 | - + |
| 70 | 20-29-137 | Pedal Lever Support Tube Assembly | 2 | 9 | £30.00 | - + |
| 62 | 125566 | Nut, Avloc, 1/4" UNF | 8 | 8 | £30.00 | - + |
| 66 | 20-29-139 | Spring Pedal Lever, RH | 1 | 1 | £30.00 | - + |
| 71 | 20-29-009 | Transverse Rod Assembly | 1 | 20 | £30.00 | - + |
| 72 | 20-29-143 | Spring, Pedal Lever, L.H. | 1 | 10 | £30.00 | - + |
| 73 | 20-29-010 | Throttle Linkage Lever Assembly | 1 | 17 | £30.00 | - + |
| 74 | 123127 | Setscrew, 1/4" UNF × 3/4" - R.H.D. | 1 | 19 | £30.00 | - + |
| - | 123127 | Setscrew, 1/4" UNF × 3/4" - L.H.D. | 2 | 18 | £30.00 | - + |
| 75 | 119480 | Spring Washer, 1/4" - R.H.D. | 1 | 8 | £30.00 | - + |
| - | 119480 | Spring Washer, 1/4" - L.H.D. | 2 | 20 | £30.00 | - + |
| 76 | 20-29-140 | Operating Rod | 1 | 14 | £30.00 | - + |
| 77 | 125526 | Ball Joint, LH Thread | 1 | 6 | £30.00 | - + |
| 78 | 110980 | Locknut, 2 BA, LH Thread | 1 | 6 | £30.00 | - + |
| 79 | 125525 | Ball joint, RH Thread | 1 | 19 | £30.00 | - + |
| 80 | 112941 | Locknut, 2 BA RH Thread | 1 | 12 | £30.00 | - + |
| 81 | 122315 | Nut, Nyloc, 2 BA | 2 | 6 | £30.00 | - + |
| 82 | 21-29-146 | Fork End | 2 | 14 | £30.00 | - + |
| - | 21-29-147 | Thrust Bar - Push Rod | 2 | 15 | £30.00 | - + |
| 83 | 125557 | Locknut, 5/16" UNF | 4 | 16 | £30.00 | - + |
| 84 | 20-29-186 | Anti-Rattle Spring - Accelerator Pedal | 1 | 1 | £30.00 | - + |
| 85 | 20-29-187 | Retainer Plate - Anti-Rattle Spring | 1 | 17 | £30.00 | - + |
Radiator and Fixings
Rear Axle and Propshaft
Rear Brakes
Rear Bulkhead
Rear Suspension
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| 1 | 20-26-001 | Radius Arm Assembly | 4 | 5 | £30.00 | - + |
| 2 | 20-26-118 | Bush, Radius Arms | 8 | 8 | £30.00 | - + |
| 3 | 20-26-119 | Bolt, Upper Radius Arm-Frame | 2 | 2 | £30.00 | - + |
| 4 | 20-26-120 | Bolt, Lower Radius Arm-Frame | 2 | 15 | £30.00 | - + |
| 5 | 20-26-135 | Bolt, Radius Arms- Axle | 4 | 5 | £30.00 | - + |
| 6 | 690326 | Special Washer, 1/2" | 4 | 15 | £30.00 | - + |
| 7 | 119474 | Plain Washer, 1/2" | 4 | 10 | £30.00 | - + |
| 8 | 690156 | Nut, Nyloc, Thin, 1/2" UNF | 8 | 16 | £30.00 | - + |
| - | 20-26-004 | Rear Axle Cover Assembly | 1 | 9 | £30.00 | - + |
| 9 | 20-26-133 | Rear Axle Cover | 1 | 8 | £30.00 | - + |
| 10 | 20-26-134 | Pin, Swinging Link | 1 | 5 | £30.00 | - + |
| 11 | 119608 | Woodruff Key, No. 9 | 1 | 19 | £30.00 | - + |
| 12 | 20-26-139 | Swinging Link | 1 | 15 | £30.00 | - + |
| 13 | 20-26-140 | Bush, Swinging Link, Centre | 1 | 8 | £30.00 | - + |
| 14 | 690325 | Special Washer, 5/8" | 1 | 10 | £30.00 | - + |
| 15 | 125595 | Nut, Nyloc, Thin, 5/8" UNF | 1 | 14 | £30.00 | - + |
| 16 | 20-26-005 | Watts Link Assembly, Upper | 1 | 13 | £30.00 | - + |
| 17 | 20-26-006 | Watts Link Assembly, Lower | 1 | 8 | £30.00 | - + |
| 18 | 20-26-146 | Bush, Watts Links | 2 | 16 | £30.00 | - + |
| 19 | 20-26-148 | Bolt - Watts Links to Frame | 2 | 6 | £30.00 | - + |
| 20 | 690326 | Special Washer, 1/2" | 2 | 7 | £30.00 | - + |
| 21 | 690156 | Nut, Nyloc, Thin 1/2" UNF | 2 | 15 | £30.00 | - + |
| 22 | 20-26-141 | Bush, Swinging Link, Outer | 2 | 15 | £30.00 | - + |
| 23 | 20-26-147 | Bolt- Watts Links to Swinging Link | 2 | 12 | £30.00 | - + |
| 24 | 119472 | Plain Washer, 3/8" | 2 | 10 | £30.00 | - + |
| 25 | 125594 | Nut, Nyloc, Thin, 3/8" UNF | 2 | 6 | £30.00 | - + |
| 26 | 20-26-138 | Road Spring | 2 | 19 | £30.00 | - + |
| 27 | 20-26-154 | Insulating Ring | 2 | 17 | £30.00 | - + |
| 28 | 20-26-136 | Metacone Spring Insulator | 2 | 13 | £30.00 | - + |
| 29 | 20-26-137 | Retaining Plate | 2 | 14 | £30.00 | - + |
| 30 | 690157 | Bolt, 3/8" UNF × 1 3/4" | 2 | 4 | £30.00 | - + |
| 31 | 119482 | Spring Washer, 3/8" | 2 | 14 | £30.00 | - + |
| 32 | 20-26-002 | Bump Stop Bracket Assembly | 2 | 14 | £30.00 | - + |
| 33 | 125519 | Bolt, 5/16" UNF × 5/8" | 8 | 12 | £30.00 | - + |
| 34 | 119481 | Spring Washer, 5/16" | 8 | 11 | £30.00 | - + |
| 35 | 20-26-125 | Bump Stop | 2 | 4 | £30.00 | - + |
| 36 | 20-26-124 | Clamping Plate | 2 | 16 | £30.00 | - + |
| 37 | 20-26-123 | Check Strap | 2 | 5 | £30.00 | - + |
| 38 | 690019 | Nut, Nyloc, Thin, 5/16" UNF | 4 | 11 | £30.00 | - + |
| 39 | 20-26-149 | Shock Absorber and Arm - R. H. | 1 | 10 | £30.00 | - + |
| 40 | 20-26-150 | Shock Absorber and Arm - L. H. | 1 | 20 | £30.00 | - + |
| 41 | 690157 | Bolt, 3/8" UNF × 1 3/4" | 8 | 16 | £30.00 | - + |
| 42 | 119472 | Plain Washer, 3/8" | 8 | 13 | £30.00 | - + |
| 43 | 123113 | Nut, Nyloc, 3/8" UNF | 8 | 14 | £30.00 | - + |
| 44 | 20-26-155 | Link Assembly, Shock Absorbers | 2 | 8 | £30.00 | - + |
| 45 | 119473 | Plain Washer, 7/16" | 4 | 4 | £30.00 | - + |
| 46 | 690154 | Nut, Nyloc, Thin, 7/16" UNF | 4 | 9 | £30.00 | - + |
| 47 | 20-26-152 | Rear Hub - R. H. | 1 | 3 | £30.00 | - + |
| 48 | 20-26-153 | Rear Hub - L. H. | 1 | 4 | £30.00 | - + |
| 49 | 20-26-760 | Plain Washer, 7/8" | 2 | 5 | £30.00 | - + |
| 50 | 20-26-759 | Slotted Nut, 7/8" UNF | 2 | 3 | £30.00 | - + |
| 51 | 20-26-758 | Split Pin, 5/32" diam. × 1 1/2" | 2 | 10 | £30.00 | - + |
| - | 20-26-159 | Cover Plate - Upper Link | 2 | 3 | £30.00 | - + |
| - | 690517 | Screw, P. K. No. 4 × 1/4". Rd. Hd. Type A | 6 | 3 | £30.00 | - + |
Remote Gear Mechanism
Service Kits
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| - | 20-43-105 | Illustrated Parts Book | 1 | 19 | £30.00 | - + |
| - | 20-43-007 | Gasket Set - Decarbonising | 1 | 19 | £30.00 | - + |
| - | 20-43-006 | Gasket Set - Complete Overhaul with 20-43-007 | 1 | 13 | £30.00 | - + |
| - | 20-43-102 | Valve Timing Jig | 1 | 9 | £30.00 | - + |
| - | 20-43-101 | Road Spring Sompression Tool | 1 | 4 | £30.00 | - + |
| - | 20-43-104 | Front Wing Cover, RH - Felt Lined Fibreglass | 1 | 16 | £30.00 | - + |
| - | 20-43-103 | Front Wing Cover, LH - Felt Lined Fibreglass | 1 | 9 | £30.00 | - + |
| - | 20-43-110 | Retractor Tool, Piston - Brake Wheel Cylinder | 1 | 16 | £30.00 | - + |
| - | 20-43-108 | Rear Axle Tooolkit | 1 | 1 | £30.00 | - + |
Steering Gear and Column
| Ill. No. | Part No. | product name | Car Total |
Stock | Price | Quantity |
|---|---|---|---|---|---|---|
| - | 20-24-001 | Steering Box Assembly | 1 | 10 | £30.00 | - + |
| - | 25-24-001 | Steering Box Assembly | 1 | 1 | £30.00 | - + |
| 1 | 20-23-111 | Steering Box Housing | 1 | 1 | £30.00 | - + |
| - | 690434 | Taper Plug, 5/16" UNF | 2 | 11 | £30.00 | - + |
| 2 | 20-24-117 | Bush | 1 | 19 | £30.00 | - + |
| 3 | 20-24-112 | Steering Rack | 1 | 5 | £30.00 | - + |
| 4 | 20-24-113 | Damper Block | 1 | 3 | £30.00 | - + |
| 5 | 20-24-114 | Spring - Damper | 1 | 11 | £30.00 | - + |
| 6 | 20-24-115 | Shim - Damper | 1 | 16 | £30.00 | - + |
| 7 | 20-24-116 | Cover | 1 | 16 | £30.00 | - + |
| 8 | 111760 | Grease Nipple. 1/8" BSP, 67 1/2 | 1 | 9 | £30.00 | - + |
| 9 | 119480 | Spring Washer, 1/4" | 2 | 7 | £30.00 | - + |
| 10 | 123128 | Setscrew, 1/4" UNC × 7/8" | 2 | 8 | £30.00 | - + |
| 11 | 20-24-126 | Locknut | 2 | 16 | £30.00 | - + |
| 12 | 20-24-127 | Tab Washer | 2 | 3 | £30.00 | - + |
| 13 | 20-24-125 | Spring - Track Rod | 2 | 2 | £30.00 | - + |
| 14 | 20-24-123 | Ball Seat | 2 | 11 | £30.00 | - + |
| 15 | 20-24-129 | Track Rod | 2 | 1 | £30.00 | - + |
| 16 | 20-24-124 | Ball End Nut | 2 | 12 | £30.00 | - + |
| 17 | 690083 | Lock Nut, 5/8" UNF | 2 | 11 | £30.00 | - + |
| 18 | 20-24-130 | Ball Joint. Track Rod End | 2 | 10 | £30.00 | - + |
| 19 | 690321 | Grease Nipple, 5/16" UNF, 67 1/2 | 2 | 8 | £30.00 | - + |
| 20 | 20-24-128 | Gaiter - Track Rod | 2 | 1 | £30.00 | - + |
| 21 | 110883 | Hose Clip | 2 | 17 | £30.00 | - + |
| - | 13489 | Copper Wire | A/R | 3 | £30.00 | - + |
| 22 | 20-24-131 | Mounting | 2 | 18 | £30.00 | - + |
| 23 | 125519 | Bolt, 5/16" UNF × 5/8" | 10 | 20 | £30.00 | - + |
| 24 | 690084 | Bolt, 5/16" UNC × 7/8" | 6 | 5 | £30.00 | - + |
| 25 | 119481 | Spring Washer, 5/16" | 16 | 13 | £30.00 | - + |
| 26 | 20-24-118 | Pinion | 1 | 3 | £30.00 | - + |
| 27 | 690054 | Taper Roller Bearing | 2 | 5 | £30.00 | - + |
| 28 | 20-24-121 | Shim - Bearing Cover, Upper | 1 | 20 | £30.00 | - + |
| 29 | 690055 | "O" Ring Seal | 1 | 10 | £30.00 | - + |
| 30 | 20-24-122 | Bearing Cover, Upper | 1 | 19 | £30.00 | - + |
| 31 | 20-24-119 | Joint - Bearing Cover, Lower | 1 | 12 | £30.00 | - + |
| 32 | 20-24-120 | Bearing Cover, Lower | 1 | 2 | £30.00 | - + |
| 33 | 119470 | Plain Washer, 1/4" | 8 | 14 | £30.00 | - + |
| 34 | 119480 | Spring Washer, 1/4" | 8 | 19 | £30.00 | - + |
| 35 | 123128 | Setscrew, 1/4" UNC × 7/8" | 8 | 9 | £30.00 | - + |
| - | 20-24-132 | Earth Bond - Steering Box to Frame | 1 | 13 | £30.00 | - + |
| 36 | 20-25-005 | Lower Tube Assmbly, Steering Column | 1 | 12 | £30.00 | - + |
| 37 | 20-25-705 | Universal Joint - Spider Assembly | 2 | 9 | £30.00 | - + |
| 38 | 20-25-137 | Support Bracket, Bulkhead | 1 | 16 | £30.00 | - + |
| - | 20-25-149 | Shim - Support Bracket | A/R | 10 | £30.00 | - + |
| 39 | 690035 | Socket Setscrew, 1/4" UNF × 7/8" | 3 | 4 | £30.00 | - + |
| 40 | 119480 | Spring Washer. 1/4" | 3 | 17 | £30.00 | - + |
| 41 | 690370 | Special Plain Washer, 1/4" | 2 | 13 | £30.00 | - + |
| 42 | 690056 | Flexible Bush | 3 | 20 | £30.00 | - + |
| 43 | 125581 | Bolt, 1/4" UNF × 1 1/8" | 2 | 16 | £30.00 | - + |
| 44 | 119480 | Spring Washer. 1/4" | 2 | 8 | £30.00 | - + |
| 45 | 119470 | Plain Washer, 1/4" | 2 | 12 | £30.00 | - + |
| 46 | 20-25-141 | Flanged Cover RH for R. H. D. LH for L. H. D. | 1 | 12 | £30.00 | - + |
| 47 | 20-25-143 | Rubber Joint | 2 | 3 | £30.00 | - + |
| - | 20-25-142 | Blanking Cover LH for R. H. D. RH for L. H. D. | 1 | 5 | £30.00 | - + |
| - | 690191 | Bolt. 2 BA × 4" | 12 | 14 | £30.00 | - + |
| - | 119496 | Plain Washer, 3/16" | 12 | 15 | £30.00 | - + |
| - | 122315 | Nut. Nyloc. 2 BA | 12 | 7 | £30.00 | - + |
| 48 | 20-25-140 | Gaiter - Column | 1 | 9 | £30.00 | - + |
| 49 | 20-25-139 | Mounting Clamp, Bulkhead | 1 | 7 | £30.00 | - + |
| 50 | 690063 | Bolt, 3/8" UNF × 3 1/2" | 1 | 16 | £30.00 | - + |
| 51 | 119472 | Plain Washer, 3/8" | 2 | 2 | £30.00 | - + |
| - | 122215 | Spacing Washer, 3/8" | 2 | 17 | £30.00 | - + |
| 52 | 123113 | Nut, Nyloc, 3/8" UNF | 1 | 18 | £30.00 | - + |
| 53 | 125589 | Socket Setscrew, 5/16" UNF × 1 1/8" - Clamp | 1 | 2 | £30.00 | - + |
| - | 119481 | Spring Washer, 5/16" | 1 | 8 | £30.00 | - + |
| - | 690371 | Special Plain Washer, 5/16" | 1 | 13 | £30.00 | - + |
| 54 | 20-25-138 | Rubber Sleeve | 1 | 18 | £30.00 | - + |
| 55 | 20-25-002 | Outer Tube Assembly, Steering Column | 1 | 11 | £30.00 | - + |
| 56 | 690367 | Circlip | 2 | 17 | £30.00 | - + |
| 57 | 123102 | Needle Roller Bearing | 2 | 10 | £30.00 | - + |
| 58 | 20-25-111 | Felt Ring | 2 | 5 | £30.00 | - + |
| 59 | 20-25-004 | Inner Tube Assembly, Steering Column | 1 | 2 | £30.00 | - + |
| 60 | 123132 | Bolt, 5/16" UNF × 1 3/8" | 2 | 11 | £30.00 | - + |
| 61 | 119481 | Spring Washer, 5/16" | 2 | 13 | £30.00 | - + |
| 62 | 125557 | Plain Nut, 5/16" UNF | 2 | 18 | £30.00 | - + |
| 63 | 20-25-112 | Top Bearing Housing | 1 | 9 | £30.00 | - + |
| 64 | 690372 | Clamp Bolt, 1/4" UNF × 2 1/4 | 1 | 14 | £30.00 | - + |
| 65 | 119470 | Plain Washer, 1/4" | 1 | 16 | £30.00 | - + |
| 66 | 123116 | Nut, Nyloc, 1/4" UNF | 1 | 18 | £30.00 | - + |
| 67 | 20-25-006 | Steering Wheel and Hub Assembly | 1 | 13 | £30.00 | - + |
| 68 | 690111 | Locating Bolt, 1/4" UNF × 1 3/8" Dull Chr.Pl. | 1 | 13 | £30.00 | - + |
| 69 | 690146 | Thackeray Spring Washer, 1/4", Cad. Pl. | 1 | 4 | £30.00 | - + |
| 70 | 690112 | Plain Nut, 1/4" UNF Dull Chr. Pl. | 1 | 12 | £30.00 | - + |
| 71 | 122070 | Snap Connector, Single | 1 | 17 | £30.00 | - + |
| 72 | 20-25-144 | Tie Plate, Steering Column Cut- out (RH for R. H. D.) ( LH for L. H. D.) | 1 | 4 | £30.00 | - + |
| - | 20-25-145 | Closing Plate, Steering Column Cut-out ( LH for R. H. D.) (RH for L. H. D.) | 1 | 11 | £30.00 | - + |
| 73 | 690037 | Bolt, 1/4" UNF × 1/2" | 8 | 20 | £30.00 | - + |
| 74 | 119480 | Spring Washer, 1/4" | 8 | 15 | £30.00 | - + |
| 75 | 125583 | Plain Nut, 1/4" UNF | 4 | 13 | £30.00 | - + |
| 76 | 20-25-150 | Contact Assembly | 1 | 11 | £30.00 | - + |
| 77 | 20-25-120 | Cantact Holder Bracket | 1 | 15 | £30.00 | - + |
| 78 | 114235 | Screw, 2 BA × 5/16", Rd. Hd. | 2 | 12 | £30.00 | - + |
| - | 119488 | Spring Washer, 3/16" | 2 | 6 | £30.00 | - + |
| 79 | 20-25-146 | Cup, Horn Push | 1 | 9 | £30.00 | - + |
| 80 | 20-25-136 | Horn Push Assembly | 1 | 2 | £30.00 | - + |
Steering Mechanism
Suspension and Steering
Timing Case
Transmission
Wheels and Tool Kit
Wheels, Tyres and Tool Kit
Windscreen Wipers and Washers
Technical Publications
For all Parts Catalogues, Workshop Manuals and Instruction Books please follow the link to the technical publications page.
DB2/4 MkIII
90222 Parts Catalogue90222 Parts Catalogue
90222 Parts Catalogue
£ 29 EA
Can't Find What You're Looking For?
INTERNATIONAL SHIPPING AVAILABLE
All payments should be made in UK Pounds Sterling (£) either by Cash, Cheque, Credit/Debit Card or Bank Transfer.
